M50-4801445

Headers, Male Pins Overview

Harwin M50-4801445 is a board-to-board connector from the Archer M50 series. It features a dual-row receptacle configuration with 40 positions and a 1.27 mm pitch. The component utilizes surface mount technology for installation and incorporates gold-plated contacts. Designed for right-angle mounting, it provides reliable interconnection in compact electronic assemblies.

Headers, Male Pins Feature Summary

• Right-angle surface mount receptacle design
• Dual-row configuration with 1.27 mm spacing
• Gold-plated contact finish

Headers, Male Pins Applications

• Board-to-board interconnections
• High-density electronic modules
• Compact consumer electronics

Headers, Male Pins Procurement Notes

Verify the specific mating height and housing material against the official Harwin datasheet before integration. Confirm that the right-angle orientation aligns with the PCB layout requirements. Ensure compatibility with the corresponding pin header within the Archer M50 product family to guarantee proper mechanical engagement and electrical performance.

Headers, Male Pins Selection Notes

Select this component when a low-profile, right-angle connection is required between two parallel boards. The 1.27 mm pitch supports high-density applications where space is limited. Verify that the operating temperature range and current ratings meet the system's thermal and electrical demands during the design phase.

Headers, Male Pins Part Context

The M50-4801445 belongs to the Archer M50 series, which offers various stacking heights and configurations. This specific part number represents a 40-position variant designed for surface mount assembly. It complements other headers and sockets within the same architectural family to create complete interconnect solutions.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other Harwin M50 series connectors with matching 1.27 mm pitch and 40 positions. Ensure the replacement maintains the right-angle orientation and dual-row structure. Cross-reference the mating height specifications to ensure mechanical fit.
