M50-4803045

Headers, Male Pins Overview

The Harwin M50-4803045 is a board-to-board connector header from the Archer M50 series. It features 60 positions arranged in a single row with a 1.27 mm (0.05 inch) pitch. The component utilizes through-hole termination and is designed for right-angle mounting. Contact plating is gold, ensuring reliable electrical performance.

Headers, Male Pins Feature Summary

• Right-angle configuration for compact PCB layout
• Shrouded four-wall design for precise mating alignment
• Gold-plated contacts for corrosion resistance

Headers, Male Pins Applications

• Compact electronic assemblies requiring space-saving connections
• Board-to-board interconnects in consumer electronics
• Industrial control systems with limited vertical clearance

Headers, Male Pins Procurement Notes

Verify the specific suffix to confirm the right-angle orientation and shrouding style. Ensure the supplier provides original manufacturer documentation to validate authenticity. Check RoHS compliance status if required by your manufacturing standards. Confirm that the package quantity matches your assembly needs.

Headers, Male Pins Selection Notes

Select this part when a right-angle connection is necessary to save vertical space on the PCB. The 1.27 mm pitch suits high-density applications. Verify that the through-hole mounting method aligns with your production capabilities. Consider the shrouded design for improved mating accuracy compared to open headers.

Headers, Male Pins Part Context

This component belongs to the Harwin Archer M50 series, known for high-reliability board-to-board connections. The series offers various configurations including surface mount and through-hole options. The M50-4803045 specifically addresses applications needing angled insertion while maintaining a small footprint.

Headers, Male Pins Replacement Considerations

Direct substitutes within the same series include other M50-48xxxxx variants with different position counts. Ensure any replacement maintains the 1.27 mm pitch and right-angle form factor. Cross-reference pinout and mechanical dimensions before swapping.
