MCMN2014HE3-TP

$0.51

Description：N-CHANNEL MOSFET, DFN2020-6LE
Series：-
Mfr：MCC (Micro Commercial Components)
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:b2052a21f0a8 Category: Single FETs, MOSFETs Brand: MCC (Micro Commercial Components)

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

MCMN2014HE3-TP is listed in the Single FETs, MOSFETs range at ChipApex. The manufacturer field lists MCC (Micro Commercial Components). Its product description is N-CHANNEL MOSFET, DFN2020-6LE. Review the specifications below when checking this part for your BOM.

Single FETs, MOSFETs specifications for MCMN2014HE3-TP

Description：N-CHANNEL MOSFET, DFN2020-6LE
Series：-
Mfr：MCC (Micro Commercial Components)
Package：Tape & Reel (TR),Cut Tape (CT)
FET Type：N-Channel
Technology：MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)：12 V
Current - Continuous Drain (Id) @ 25°C：15A
Drive Voltage (Max Rds On, Min Rds On)：2.5V, 8V
Rds On (Max) @ Id, Vgs：8mOhm @ 5A, 8V
Vgs(th) (Max) @ Id：1.1V @ 250µA
Gate Charge (Qg) (Max) @ Vgs：48 nC @ 8 V
Vgs (Max)：±8V
Input Capacitance (Ciss) (Max) @ Vds：1791 pF @ 10 V
FET Feature：-
Power Dissipation (Max)：-
Operating Temperature：-55°C ~ 150°C (TJ)
Grade：Automotive
Qualification：AEC-Q101
Mounting Type：Surface Mount
Supplier Device Package：DFN2020-6LE
Package / Case：6-VDFN Exposed Pad

Single FETs, MOSFETs datasheet and documents for MCMN2014HE3-TP

MCMN2014HE3-TP

Single FETs, MOSFETs Overview

The MCMN2014HE3-TP is a 12V N-channel MOSFET utilizing trench LV technology in a DFN2020-6LE package. It features a drain-source breakdown voltage of 12V, continuous drain current of 15A at 25°C, and typical on-resistance of 8mΩ at VGS=8V. The device supports a junction temperature range of -55°C to +150°C with AEC-Q101 qualification.

Single FETs, MOSFETs Feature Summary

Trench LV MOSFET technology for low on-resistance
AEC-Q101 qualified for automotive reliability
Halogen-free "Green" device compliant with RoHS

Single FETs, MOSFETs Applications

Automotive power management systems
Low voltage DC-DC converter circuits
Load switching applications

Single FETs, MOSFETs Procurement Notes

Verify the authenticity of the MCMN2014HE3-TP by purchasing directly from Micro Commercial Components or authorized distributors. Counterfeit prevention measures are strictly enforced; parts from unauthorized sources lack warranty coverage. Confirm the DFN2020-6LE package type and tape-and-reel quantity specifications match your manufacturing requirements before finalizing orders.

Single FETs, MOSFETs Selection Notes

Select this component for designs requiring a 12V rated N-channel switch with high current capability. The DFN2020-6LE package offers compact footprint suitability for space-constrained PCB layouts. Ensure thermal management accounts for the 52.5°C/W junction-to-ambient resistance when operating near maximum ratings.

Single FETs, MOSFETs Part Context

This part belongs to the MCC N-channel MOSFET family designed for low-voltage switching applications. The HE3 suffix indicates Halogen-free environmental compliance, while the TP suffix denotes Tape & Reel packaging. The DFN2020-6LE package provides efficient thermal dissipation for surface-mount assembly processes.
