MHB110426G306

Overview

The Hoffman MHB110426G306 is a wall-mount enclosure constructed from glass-filled polypropylene, featuring a translucent gray finish. It measures 11 inches in height, 4 inches in width, and 26 inches in depth. The unit provides an IP65 rating when sealed with the included gasket and offers UL Type 12 protection against dust, falling dirt, and dripping non-corrosive liquids. Designed for industrial environments, it includes a hinged door with a quarter-turn fastener mechanism and supports DIN rail mounting internally.

Feature Summary

• Constructed from durable glass-filled polypropylene material
• Provides ingress protection against dust and liquid splashes
• Features a hinged door with secure quarter-turn latching
• Includes internal mounting provisions for standard components

Applications

• Industrial control panel housing
• Electrical component protection in manufacturing facilities
• Enclosure for automation system interfaces
• Protection for sensors and signal conditioning modules

Procurement Notes

Verify that the specific order matches the model suffix G306 to ensure the correct translucent gray color and polypropylene composition. Confirm that the required IP65 rating is achievable by ensuring all cable entries are properly sealed with appropriate glands, as the rating depends on complete assembly integrity. Check for any regional compliance requirements regarding material flammability ratings before finalizing procurement.

Selection Notes

Select this model when a lightweight, corrosion-resistant enclosure is required for indoor or sheltered outdoor use. The translucent material allows for visual inspection of internal status indicators without opening the door. Ensure the internal volume accommodates all components plus necessary clearance for heat dissipation and wiring. Consider the mounting orientation and available space relative to the 11x4x26 inch external dimensions.

Part Context

This part belongs to the Hoffman MHB series of general-purpose enclosures designed for cost-effective protection of electrical and electronic equipment. The series utilizes thermoplastic materials to offer resistance to chemicals and moisture while maintaining structural integrity. It serves as a standard solution for applications where metal enclosures are unnecessary or where weight reduction is a priority.

Replacement Considerations

Direct replacements must match the 11x4x26 inch footprint and IP65 rating. Verify compatibility with existing DIN rails and mounting hardware. Alternative materials such as polycarbonate may offer higher impact resistance but differ in chemical compatibility.
