MPXC2012DT1

Pressure Sensors Transducers Overview

The MPXC2012DT1 is a miniature differential pressure sensor manufactured by Freescale Semiconductor. It features a 4-SSIP module package with an output range of 0 mV to 25 mV at 10V excitation. The device measures differential pressure up to 1.45 PSI (10 kPa). The chip design exposes die and wire bonds on the front side, requiring pressure application to the backside of the device.

Pressure Sensors Transducers Feature Summary

• Miniature package suitable for sub-module integration
• Differential pressure sensing capability
• Exposed die construction for specific mounting requirements

Pressure Sensors Transducers Applications

• Low pressure applications
• Sub-module component integration
• Disposable unit implementations

Pressure Sensors Transducers Procurement Notes

Verify the manufacturer designation as Freescale Semiconductor or NXP Semiconductors due to corporate history. Confirm the package type is 4-SSIP and the pressure rating matches 1.45 PSI (10 kPa) differential. Ensure handling procedures account for the exposed die and wire bonds on the front side, as pressure must be applied to the backside.

Pressure Sensors Transducers Selection Notes

Select this component for low-pressure differential measurement tasks requiring a compact form factor. Consider the exposed die configuration when designing the mechanical interface, as pressure application must target the backside. Verify compatibility with the specified 0 mV to 25 mV output range under 10V excitation for signal conditioning circuitry.

Pressure Sensors Transducers Part Context

This part belongs to the PXC20 series of high-volume sensors designed for low-pressure applications. The series includes variants like MPXC2011DT1. Freescale Semiconductor developed these miniature packages to serve as efficient sub-module components or disposable units in various industrial and consumer applications.

Pressure Sensors Transducers Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Cross-reference with other PXC20 series variants such as MPXC2011DT1 if similar specifications are required, but verify exact electrical and mechanical parameters before substitution.
