N3764-6302RB

Headers, Male Pins Overview

The N3764-6302RB is a 64-position, two-row PCB header from the 3M 3000 Series. It features a 2.54 mm pitch and straight body orientation for board-to-board or wire-to-board connections. The connector utilizes through-hole termination with solder tails and gold-plated copper alloy contacts. Rated for 25 V and up to 2.0 A current, it operates within a temperature range of -55°C to 105°C. The shrouded design includes long latch pins for secure mating.

Headers, Male Pins Feature Summary

• Shrouded housing provides alignment and protection for contact insertion
• Gold-plated copper alloy contacts ensure reliable conductivity and corrosion resistance
• Long solder tail design facilitates robust through-hole mounting on printed circuit boards

Headers, Male Pins Applications

• Board-to-board interconnections in electronic assemblies
• Wire-to-board connections requiring high-density pin counts
• Industrial control systems operating within specified thermal limits

Headers, Male Pins Procurement Notes

Verify that the specific part number matches the required 64-contact configuration and shrouded style. Confirm that the through-hole termination type aligns with the target PCB layout and soldering process capabilities. Ensure environmental ratings meet operational temperature requirements.

Headers, Male Pins Selection Notes

Select this component when a high-density, two-row header is necessary for signal or power distribution. Consider the 2.54 mm pitch constraint and the need for shrouded alignment features. Evaluate current rating requirements against the 2.0 A specification to ensure adequate performance margins.

Headers, Male Pins Part Context

This component belongs to the 3M 3000 Series, which offers various configurations of PCB headers. The series is designed for general electronic applications requiring reliable interconnects. The N3764-6302RB specifically addresses needs for higher pin counts with a straight, shrouded form factor.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 64-pin count, 2-row arrangement, 2.54 mm pitch, and shrouded design. Verify compatibility with existing PCB footprints and mating receptacles before substitution.
