NJU7074M#

$1.28

Description：IC CMOS 4 CIRCUIT 14SSOP
Series：-
Mfr：Nisshinbo Micro Devices Inc.
Package：Tube

SKU:18d7f1fb6a0c Category: Instrumentation, Op Amps, Buffer Amps Brand: Nisshinbo Micro Devices Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

NJU7074M# is listed in the Instrumentation, Op Amps, Buffer Amps range at ChipApex. The manufacturer field lists Nisshinbo Micro Devices Inc.. Its product description is IC CMOS 4 CIRCUIT 14SSOP. Review the specifications below when checking this part for your BOM.

Instrumentation, Op Amps, Buffer Amps specifications for NJU7074M#

Description：IC CMOS 4 CIRCUIT 14SSOP
Series：-
Mfr：Nisshinbo Micro Devices Inc.
Package：Tube
Amplifier Type：CMOS
Number of Circuits：4
Output Type：Rail-to-Rail
Slew Rate：1.1V/µs
Gain Bandwidth Product：1 MHz
Current - Input Bias：1 pA
Voltage - Input Offset：2 mV
Current - Supply：600µA (x4 Channels)
Current - Output / Channel：-
Voltage - Supply Span (Min)：5 V
Voltage - Supply Span (Max)：16 V
Operating Temperature：-20°C ~ 75°C
Grade：-
Qualification：-
Mounting Type：Surface Mount
Package / Case：14-LSSOP (0.173", 4.40mm Width)
Supplier Device Package：14-SSOP
-3db Bandwidth：-

Instrumentation, Op Amps, Buffer Amps datasheet and documents for NJU7074M#

NJU7074M#

Instrumentation, Op Amps, Buffer Amps Overview

The NJU7074M is a quad C-MOS operational amplifier designed for single-power-supply operation. It features a low input offset voltage of 2 mV maximum and an input bias current of 1 pA typical, enabling the amplification of signals near ground level. The device operates within a supply voltage range of 5 V to 16 V and delivers a rail-to-rail output swing. Each circuit consumes approximately 0.6 mA of operating current. Key electrical parameters include a unity gain bandwidth of 1 MHz, a slew rate of 1.1 V/µs, and a common mode rejection ratio of 60 dB.

Instrumentation, Op Amps, Buffer Amps Feature Summary

Quad configuration with internal compensation capacitor
Rail-to-rail output capability on single power supply
Low input offset voltage and bias current for precision applications
CMOS technology ensuring low power consumption

Instrumentation, Op Amps, Buffer Amps Applications

Battery-operated instrumentation circuits
Signal conditioning for small voltage levels near ground
General-purpose analog signal processing

Instrumentation, Op Amps, Buffer Amps Procurement Notes

Verify the specific package variant (DMP or SSOP) required for your design, as the datasheet lists multiple package options for this part number. Confirm that the operating temperature range of -20°C to +75°C aligns with your system requirements. Ensure supply voltage does not exceed 18 V absolute maximum rating during implementation.

Instrumentation, Op Amps, Buffer Amps Selection Notes

Select this component when a quad amplifier configuration is needed with low quiescent current and rail-to-rail output performance. It is suitable for designs requiring high input impedance and minimal offset voltage without external nulling adjustments, which are only available in the single-channel variant.

Instrumentation, Op Amps, Buffer Amps Part Context

This component belongs to the NJU707x series, which includes single (NJU7071), dual (NJU7072), and quad (NJU7074) operational amplifiers. All variants share identical electrical characteristics but differ in channel count and pinout configurations. The series utilizes CMOS technology optimized for low-voltage, low-power single-supply applications.
