NTLUS4195PZTAG

$0.25

Description：MOSFET P-CH 30V 2A 6UDFN
Series：-
Mfr：onsemi
Package：Tape & Reel (TR),Bulk

SKU:71327dde42dc Category: Single FETs, MOSFETs Brand: onsemi

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

NTLUS4195PZTAG is listed in the Single FETs, MOSFETs range at ChipApex. The manufacturer field lists onsemi. Its product description is MOSFET P-CH 30V 2A 6UDFN. Review the specifications below when checking this part for your BOM.

Single FETs, MOSFETs specifications for NTLUS4195PZTAG

Description：MOSFET P-CH 30V 2A 6UDFN
Series：-
Mfr：onsemi
Package：Tape & Reel (TR),Bulk
FET Type：P-Channel
Technology：MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)：30 V
Current - Continuous Drain (Id) @ 25°C：2A (Ta)
Drive Voltage (Max Rds On, Min Rds On)：4.5V, 10V
Rds On (Max) @ Id, Vgs：90mOhm @ 3A, 10V
Vgs(th) (Max) @ Id：3V @ 250µA
Gate Charge (Qg) (Max) @ Vgs：5 nC @ 4.5 V
Vgs (Max)：±20V
Input Capacitance (Ciss) (Max) @ Vds：250 pF @ 15 V
FET Feature：-
Power Dissipation (Max)：600mW (Ta)
Operating Temperature：-55°C ~ 150°C (TJ)
Grade：-
Qualification：-
Mounting Type：Surface Mount
Supplier Device Package：6-UDFN (1.6x1.6)
Package / Case：6-PowerUFDFN

Single FETs, MOSFETs datasheet and documents for NTLUS4195PZTAG

NTLUS4195PZTAG

Single FETs, MOSFETs Overview

The NTLUS4195PZTAG is a surface-mount P-channel MOSFET manufactured by onsemi. It features a 30V drain-source voltage rating and a continuous drain current of 2A at ambient temperature. The device utilizes a 6-UDFN (1.6x1.6mm) package with a maximum power dissipation of 600mW. Key electrical characteristics include a gate-source voltage limit of ±20V, a threshold voltage of 3V at 250µA, and a gate charge of 5nC at 4.5V. The input capacitance is specified as 250pF at 15V. The component operates within a junction temperature range of -55°C to 150°C.

Single FETs, MOSFETs Feature Summary

Dual-gate architecture optimized for low gate charge and fast switching performance
Compact 6-UDFN package designed for high-density circuit board layouts
Enhanced thermal stability supporting operation up to 150°C junction temperature

Single FETs, MOSFETs Applications

Battery protection circuits in portable electronic devices
Load switch applications in mobile communication equipment
Power management modules requiring compact form factors

Single FETs, MOSFETs Procurement Notes

Verify the specific suffix 'TAG' against official documentation to confirm tape and reel packaging specifications. Confirm RoHS compliance status through the manufacturer's environmental declarations. Check for active obsolescence notices or product change notifications prior to finalizing procurement plans.

Single FETs, MOSFETs Selection Notes

Select this component when a small footprint P-channel MOSFET is required for low-voltage switching applications. Ensure the design accommodates the 600mW power dissipation limit under expected operating conditions. Verify that the 30V voltage rating provides sufficient margin for the target system supply rails.

Single FETs, MOSFETs Part Context

This part belongs to the NTLUS41 series of dual-gate power MOSFETs from onsemi. These devices are engineered for efficiency in space-constrained environments. The series typically targets consumer electronics and battery-powered systems where size and switching speed are critical design parameters.
