PA4344.332NLT

$2.85

Description：FIXED IND 3.3UH 28A 3.9 MOHM SMD
Series：PA4344.XXXNLT
Mfr：Pulse Electronics
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:f91e0416207a Category: Fixed Inductors Brand: Pulse Electronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

PA4344.332NLT is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Pulse Electronics. Its product description is FIXED IND 3.3UH 28A 3.9 MOHM SMD. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for PA4344.332NLT

Description：FIXED IND 3.3UH 28A 3.9 MOHM SMD
Series：PA4344.XXXNLT
Mfr：Pulse Electronics
Package：Tape & Reel (TR),Cut Tape (CT)
Type：Molded
Material - Core：-
Inductance：3.3 µH
Tolerance：-
Current Rating (Amps)：28 A
Current - Saturation (Isat)：45A
Shielding：Shielded
DC Resistance (DCR)：3.9mOhm Max
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：AEC-Q200
Operating Temperature：-40°C ~ 125°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.697" L x 0.677" W (17.70mm x 17.20mm)
Height - Seated (Max)：0.276" (7.00mm)
Features：-

Fixed Inductors datasheet and documents for PA4344.332NLT

PA4344.332NLT

Fixed Inductors Overview

The PA4344.332NLT is a shielded, molded power inductor from Pulse Electronics, designed for surface-mount applications. It features an inductance of 3.3 µH with a tolerance of ±20%. The component supports a maximum DC current of 28 A and a saturation current of 45 A. Its maximum DC resistance is 3.9 mΩ. The package dimensions are 17.7 mm x 17.2 mm x 7 mm. It operates within a temperature range of -55°C to +125°C and holds AEC-Q200 qualification.

Fixed Inductors Feature Summary

Shielded construction minimizes electromagnetic interference.
Molded core design enhances mechanical stability.
AEC-Q200 qualified for automotive reliability standards.

Fixed Inductors Applications

High current power supply circuits
Automotive electronic systems
Point-of-load conversion modules

Fixed Inductors Procurement Notes

Verify the specific ordering suffix against official Pulse Electronics documentation to ensure correct packaging configuration. Confirm that the AEC-Q200 qualification status aligns with project requirements. Cross-reference the manufacturer part number with authorized distributor catalogs to validate authenticity and technical specifications before finalizing procurement orders.

Fixed Inductors Selection Notes

Select this component when high current handling capability is required alongside low profile constraints. The 28 A continuous current rating and 45 A saturation point suit demanding power delivery tasks. Ensure the PCB footprint accommodates the 17.7 mm by 17.2 mm dimensions. Verify thermal management strategies for operation near the upper temperature limit.

Fixed Inductors Part Context

This part belongs to the PA4344.XXXNLT series of high-power surface-mount inductors. The series offers various inductance values while maintaining consistent physical dimensions and shielding characteristics. It targets applications requiring robust performance in compact spaces, particularly within automotive and industrial sectors where reliability is critical.

Fixed Inductors Replacement Considerations

Consult official substitution lists for compatible parts within the same series or alternative manufacturers offering identical electrical parameters and footprint compatibility.
