PT7M6130NLTA3EX

$0.17

Description：IC SUPERVISOR 1 CHANNEL SOT23-3
Series：-
Mfr：Diodes Incorporated
Package：Tape & Reel (TR)

SKU:c5ffaa9e979f Category: Supervisors Brand: Diodes Incorporated

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

PT7M6130NLTA3EX is listed in the Supervisors range at ChipApex. The manufacturer field lists Diodes Incorporated. Its product description is IC SUPERVISOR 1 CHANNEL SOT23-3. Review the specifications below when checking this part for your BOM.

Supervisors specifications for PT7M6130NLTA3EX

Description：IC SUPERVISOR 1 CHANNEL SOT23-3
Series：-
Mfr：Diodes Incorporated
Package：Tape & Reel (TR)
Type：Simple Reset/Power-On Reset
Number of Voltages Monitored：1
Voltage - Threshold：3V
Output：Open Drain or Open Collector
Reset：Active Low
Reset Timeout：200µs Maximum
Operating Temperature：-40°C ~ 85°C (TA)
Mounting Type：Surface Mount
Package / Case：TO-236-3, SC-59, SOT-23-3
Supplier Device Package：SOT-23-3
Grade：-
Qualification：-

Supervisors datasheet and documents for PT7M6130NLTA3EX

PT7M6130NLTA3EX

Supervisors Overview

The PT7M6130NLTA3EX is a single-channel power supply support circuit manufactured by Diodes Incorporated. It operates within a supply voltage range of 1.2 V to 5.5 V and features a fixed detection threshold voltage of 3.0 V. The device is housed in a lead-free SOT-23 package with three pins. It supports an industrial operating temperature range from -40 °C to +85 °C.

Supervisors Feature Summary

Monitors system voltages using a precision bandgap reference and comparator
Provides reliable power supply supervision without external components
Operates efficiently at low quiescent current levels

Supervisors Applications

Battery-powered portable electronics
Consumer electronic devices requiring voltage monitoring
Industrial systems needing power supply support circuits

Supervisors Procurement Notes

Verify the specific suffix TA3EX corresponds to the required reel packaging configuration. Confirm RoHS compliance status matches project requirements. Ensure the SOT-23 footprint aligns with the PCB layout design. Check for any specific handling instructions related to moisture sensitivity level one classification during assembly processes.

Supervisors Selection Notes

Select this component when a fixed 3.0 V threshold is required for voltage supervision. Consider the SOT-23 package size for space-constrained designs. Evaluate the -40 °C to +85 °C temperature range against environmental conditions. Compare power consumption specifications if ultra-low standby current is critical for battery life extension in the target application.

Supervisors Part Context

This part belongs to the PT7M61xx series of ultra-low-power voltage detectors. These circuits are designed to monitor battery, power-supply, and system voltages. The series includes various fixed and adjustable threshold options to accommodate different voltage monitoring needs across consumer and industrial applications.
