R573F93005

RF Switches Overview

The R573F93005 is an SP10T RF coaxial switch from the RAMSES series, manufactured by Radiall USA. It utilizes SMA connectors and operates up to a frequency of 22 GHz. The device features latching technology for power retention without continuous energy input. Designed for robust performance in high-frequency applications, it supports a 28 VDC control voltage. The component is engineered to provide reliable signal routing in complex RF systems requiring multiple path selection.

RF Switches Feature Summary

• SP10T configuration enabling ten distinct output paths
• Latching mechanism ensures state retention without constant power
• SMA connector interface for standardized integration
• Operational capability up to 22 GHz frequency range

RF Switches Applications

• High-frequency test and measurement equipment
• Telecommunications infrastructure signal routing
• Aerospace and defense radar systems
• Electronic warfare simulation environments

RF Switches Procurement Notes

Verify current availability status directly with the manufacturer or authorized distributors, as lifecycle information may vary. Confirm technical specifications against the latest official datasheet prior to integration. Ensure compatibility with 28 VDC control requirements and SMA mating interfaces. Check for any regional distribution restrictions or specific handling instructions relevant to high-frequency components.

RF Switches Selection Notes

Select this component when a single-pole ten-throw switching solution is required within the 22 GHz spectrum. The latching feature makes it suitable for applications where power efficiency during state holding is critical. Ensure the system design accommodates the physical dimensions and thermal characteristics associated with RAMSES series switches. Verify that the SMA interface aligns with existing cabling and fixture standards.

RF Switches Part Context

This part belongs to the RAMSES family of coaxial switches, which are designed for demanding RF environments. Radiall USA specializes in standard coaxial devices including terminations, attenuators, couplers, detectors, and switches. The RAMSES line typically offers high reliability and performance metrics suitable for industrial and scientific applications requiring precise signal management.

RF Switches Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Users should consult the manufacturer's official cross-reference guides or contact Radiall USA directly for verified equivalent components. Ensure any replacement matches the SP10T topology, SMA interface, and 22 GHz operational limits.
