RSHN-2020LD

Power Line Filter Modules Overview

The RSHN-2020LD is a single-phase EMI/EMC power line filter manufactured by TDK-Lambda. It features a rated voltage of 250VAC and a rated current of 20A. The unit supports AC and DC applications with an operating frequency range of 25Hz to 85Hz. Designed for panel mounting, it utilizes terminal block connections for secure installation.

Power Line Filter Modules Feature Summary

• Two-stage attenuation design for high noise suppression
• Panel mount construction for robust industrial integration
• Terminal block interface for reliable electrical connection

Power Line Filter Modules Applications

• Industrial control systems
• Medical equipment power supplies
• Communication infrastructure
• Semiconductor manufacturing devices

Power Line Filter Modules Procurement Notes

Verify the specific suffix LD against official TDK-Lambda documentation to confirm exact terminal configuration and compliance status. Ensure the selected variant matches the required panel cutout dimensions and terminal type for your specific enclosure design before finalizing procurement.

Power Line Filter Modules Selection Notes

Select this component when a two-stage filtering solution is required for single-phase circuits up to 20A. Confirm that the 250VAC rating and 25-85Hz frequency range align with the target system's input specifications and environmental conditions.

Power Line Filter Modules Part Context

This model belongs to the RSHN series of EMI filters from TDK-Lambda. The series offers rated currents ranging from 3A to 300A at 250VAC. These filters are engineered for high reliability in critical electronic systems requiring effective electromagnetic interference reduction.

Power Line Filter Modules Replacement Considerations

Consult official TDK-Lambda substitution guides for verified alternatives. Cross-reference current ratings, voltage limits, and physical dimensions to ensure compatibility with existing board layouts and thermal management requirements.
