RV7L020GNTCR1

Single FETs, MOSFETs Overview

The RV7L020GNTCR1 is an N-channel MOSFET designed for switching and load switch applications. It features a drain-source voltage (V_DSS) of 60V and a continuous drain current (I_D) of 2A. The device offers low on-resistance, with typical values of 0.14Ω at V_GS = 4.5V and 0.114Ω at V_GS = 10V. Total gate charge (Q_g) is 2.1nC, and power dissipation (P_D) is 1.1W. It operates within a storage temperature range of -55°C to 150°C.

Single FETs, MOSFETs Feature Summary

• Low on-resistance optimized for efficient switching performance
• Suitable for high-side load switch and general switching circuits
• Compact DFN1212-3 surface mount package

Single FETs, MOSFETs Applications

• Switching circuits
• High-side load switches
• General purpose power management

Single FETs, MOSFETs Procurement Notes

Verify the complete part number including the suffix 'TCR1' to ensure correct taping packaging configuration. Confirm that the application does not require automotive grade qualification, as this standard-grade component is explicitly not recommended for vehicle-mounted equipment. Check RoHS compliance status if required by specific environmental regulations.

Single FETs, MOSFETs Selection Notes

Select this component for low-power switching applications requiring a 60V rating and compact footprint. The DFN1212-3 package is suitable for space-constrained designs. Ensure the drive voltage aligns with the specified thresholds for optimal R_DS(on) performance. Consider thermal management capabilities given the 1.1W power dissipation limit in the small package.

Single FETs, MOSFETs Part Context

This part belongs to Rohm Semiconductor's lineup of N-channel MOSFETs. It is categorized as a standard-grade product intended for general electronic equipment rather than automotive or high-reliability industrial systems. The device utilizes a lead-free plating process compliant with RoHS directives.

Single FETs, MOSFETs Replacement Considerations

Consult official datasheets for direct pin-compatible substitutes with matching voltage and current ratings. Verify that any replacement maintains the same DFN1212-3 package dimensions and electrical characteristics such as R_DS(on) and Q_g.
