SL 10 SMD 078 7 Z

Headers, Male Pins Overview

The SL 10 SMD 078 7 Z is a board connector manufactured by Fischer Elektronik. It features five male contacts arranged in a single row with a straight orientation for surface mount terminal installation. The component utilizes a tin-plated finish on both mating and termination contacts. It is designed with a staggered configuration and complies with RoHS standards, being lead-free. The part belongs to the SL series of male headers intended for SMD mounting.

Headers, Male Pins Feature Summary

• Surface mount terminal design for direct PCB integration
• Male contact gender with staggered configuration
• Tin-plated contact surfaces for reliable connection

Headers, Male Pins Applications

• Board-to-board interconnection
• Wire-to-board assembly
• General electronic circuit mounting

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the manufacturer's current datasheet to confirm contact plating and packaging options. Ensure the selected variant matches the required pin count and mounting style. Cross-reference the part number with official Fischer Elektronik documentation to validate compliance status and physical dimensions before procurement.

Headers, Male Pins Selection Notes

Select this component for applications requiring a low-profile, surface-mounted header with five positions. Consider the tin-plated finish for general-purpose use where gold plating is not strictly necessary. Verify that the straight, single-row form factor fits within the available board space and aligns with mating connector requirements.

Headers, Male Pins Part Context

This part belongs to the Fischer Elektronik SL series of male headers designed for surface mount technology. The series offers various contact counts and plating options to suit different assembly needs. The SL 10 SMD designation indicates a specific configuration within this family, focusing on compact, reliable connections for modern electronics manufacturing processes.

Headers, Male Pins Replacement Considerations

Consult Fischer Elektronik's official substitution guide for compatible alternatives. Verify that any replacement part maintains the same 2.54 mm pitch, five-contact count, and surface mount compatibility. Ensure mechanical and electrical specifications match the original design requirements.
