SL 12 SMD 109 12 G B TR

Headers, Male Pins Overview

The SL 12 SMD 109 12 G B TR is a male pin header connector from the Fischer Elektronik SL 12 SMD series. It features a 12-position, single-row configuration with a 2.54 mm pitch. Designed for surface mount technology (SMD), this right-angle connector provides a board-to-board or wire-to-board interface. The component includes gold-plated contacts and supports an insertion depth of 5.20 mm on the PCB. It operates within a temperature range of -40°C to +163°C.

Headers, Male Pins Feature Summary

• Surface mount right-angle design for automated assembly
• Single row 12-contact configuration with 2.54 mm spacing
• Gold-plated contact surfaces for reliable conductivity

Headers, Male Pins Applications

• Board-to-board interconnections in compact electronics
• Wire-to-board connections in industrial control systems
• Signal routing in consumer electronic devices

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the manufacturer's current datasheet to ensure compatibility with required plating thickness and reel specifications. Confirm that the 'TR' designation matches the intended tape-and-reel packaging requirements for your manufacturing line. Cross-reference the exact part number with official distributor catalogs to avoid discrepancies in contact count or orientation.

Headers, Male Pins Selection Notes

Select this component when a low-profile, right-angle SMD header is required for high-density layouts. Ensure the PCB footprint accommodates the specified insertion depth and mechanical constraints. Consider the operating temperature range and contact material suitability for the target application environment before finalizing the design.

Headers, Male Pins Part Context

This part belongs to the SL 12 SMD series, which offers various pole counts and configurations for surface mount applications. Fischer Elektronik manufactures these connectors to provide robust electrical connections in space-constrained designs. The series is known for its reliability in demanding industrial and commercial environments.

Headers, Male Pins Replacement Considerations

Direct substitutes include other SL 12 SMD variants with identical pitch and row count but different contact numbers, such as SL 12 SMD 109 10 G B TR or SL 12 SMD 109 14 G B TR, provided the mechanical fit and electrical requirements are met.
