SLY 8 SMD 045 30 Z B TR

Headers, Male Pins Overview

The SLY 8 SMD 045 30 Z B TR is a surface mount pin header from the Fischer Elektronik SLY 8 SMD series. It features a 2-row configuration with 30 contacts and a 2.00 mm pitch. The connector utilizes a right-angle orientation for board-to-board or wire-to-board connections. Key specifications include a current rating of 3 A, an overall height of 6.5 mm, and a reel diameter of Ø 330 mm designed for automatic assembly. The contact length is 4.50 mm.

Headers, Male Pins Feature Summary

• Surface mount construction with push-pull fastening type
• Right-angle orientation for compact board integration
• Designed for automatic assembly via tape and reel packaging

Headers, Male Pins Applications

• Board-to-board interconnections
• Wire-to-board connections
• Automated PCB assembly processes

Headers, Male Pins Procurement Notes

Verify that the specific ordering suffix matches the required contact count and row configuration. Confirm the reel diameter specification aligns with your automated pick-and-place equipment capabilities. Ensure the surface mount termination type is compatible with your soldering profile and PCB pad design to guarantee reliable mechanical and electrical performance.

Headers, Male Pins Selection Notes

Select this component when a right-angle surface mount header with a 2.00 mm pitch is required. Consider the 3 A current rating and 6.5 mm height constraints for your enclosure space. Verify that the 30-contact layout fits within your available board area and that the automatic assembly requirements are met by the tape and reel format.

Headers, Male Pins Part Context

This part belongs to the SLY 8 SMD series of pin headers manufactured by Fischer Elektronik. The series offers various contact counts and configurations suitable for high-density electronic applications. The SLY 8 SMD line is characterized by its surface mount compatibility and standardized 2.00 mm pitch dimensions.

Headers, Male Pins Replacement Considerations

Compatible substitutes include SLY 8 SMD 045 30 G B TR and SLY 8 SMD 045 30 S B SM, which share similar series characteristics but may differ in specific ordering suffixes or termination details.
