SM2011A-R68MHF

Fixed Inductors Overview

The SM2011A-R68MHF is a fixed molded inductor manufactured by ITG Electronics, Inc. It features an unshielded design with a nominal inductance of 680 nH and a tolerance of ±20%. The component supports a maximum current rating of 9 A and exhibits a maximum DC resistance of 11.5 mΩ. It utilizes a nonstandard surface-mount package suitable for high-current applications.

Fixed Inductors Feature Summary

• Unshielded molded construction
• High current handling capability
• Surface mount chip form factor

Fixed Inductors Applications

• General purpose inductor circuits
• High current inductor applications

Fixed Inductors Procurement Notes

Verify the specific manufacturer datasheet to confirm electrical parameters such as saturation current and thermal ratings. Ensure the unshielded design aligns with electromagnetic interference requirements for the target application. Confirm RoHS compliance status through official documentation before integration.

Fixed Inductors Selection Notes

Select this component for applications requiring a compact, high-current inductor with low DC resistance. The unshielded design may require careful layout consideration regarding magnetic field interaction. Verify that the 9 A current rating meets the peak load requirements of the circuit design.

Fixed Inductors Part Context

This part belongs to the SM2011A series of fixed inductors from ITG Electronics, Inc. The series includes various inductance values tailored for general-purpose and high-current applications. The SM2011A variant specifically denotes a molded, unshielded construction style within this product line.

Fixed Inductors Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source data. Cross-referencing requires consulting official manufacturer substitution guides or equivalent specifications from other vendors.
