SP1020-01WTG

SP1020-01WTG is listed in the Tvs Diodes range at ChipApex. The manufacturer field lists Littelfuse Inc.. Its product description is TVS DIODE 6VWM 10VC 2FLIPCHIP. Review the specifications below when checking this part for your BOM.

Tvs Diodes specifications for SP1020-01WTG

• Description：TVS DIODE 6VWM 10VC 2FLIPCHIP
• Series：SP1020, SPA®
• Mfr：Littelfuse Inc.
• Package：Tape & Reel (TR),Cut Tape (CT)
• Type：Zener
• Bidirectional Channels：1
• Voltage - Reverse Standoff (Typ)：6V (Max)
• Voltage - Breakdown (Min)：-
• Voltage - Clamping (Max) @ Ipp：10V
• Current - Peak Pulse (10/1000µs)：2A (8/20µs)
• Power - Peak Pulse：-
• Power Line Protection：No
• Applications：General Purpose
• Capacitance @ Frequency：-
• Operating Temperature：-40°C ~ 125°C (TJ)
• Mounting Type：Surface Mount
• Package / Case：01005 (0402 Metric)
• Supplier Device Package：2-FlipChip
• Unidirectional Channels：-
• Grade：-
• Qualification：-

Tvs Diodes datasheet and documents for SP1020-01WTG
