SRP5030CC-2R2M

$0.60

Description：IND SMD 2.2UH 7A
Series：SRP5030CC
Mfr：Bourns Inc.
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:f6c4634e4ac3 Category: Fixed Inductors Brand: Bourns Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

SRP5030CC-2R2M is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Bourns Inc.. Its product description is IND SMD 2.2UH 7A. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for SRP5030CC-2R2M

Description：IND SMD 2.2UH 7A
Series：SRP5030CC
Mfr：Bourns Inc.
Package：Tape & Reel (TR),Cut Tape (CT)
Type：Wirewound
Material - Core：Carbonyl Powder
Inductance：2.2 µH
Tolerance：±20%
Current Rating (Amps)：7:00 AM
Current - Saturation (Isat)：8A
Shielding：Shielded
DC Resistance (DCR)：32mOhm Max
Q @ Freq：-
Frequency - Self Resonant：33MHz
Ratings：-
Operating Temperature：-40°C ~ 125°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.224" L x 0.205" W (5.70mm x 5.20mm)
Height - Seated (Max)：0.118" (3.00mm)
Features：-

Fixed Inductors datasheet and documents for SRP5030CC-2R2M

SRP5030CC-2R2M

Fixed Inductors Overview

The SRP5030CC-2R2M is a shielded wirewound power inductor from Bourns Inc., designed for surface mount applications. It features a nominal inductance of 2.2 µH with a tolerance of ±20%. The component supports a maximum DC current of 7 A and a saturation current of 10 A, while maintaining a maximum DC resistance of 32 mΩ. Its physical dimensions are non-standard, measuring approximately 5.0 mm in length, 5.0 mm in width, and 3.0 mm in height. The unit operates within a temperature range of -40°C to +125°C.

Fixed Inductors Feature Summary

Shielded wirewound construction minimizes electromagnetic interference
High saturation current capability for demanding power circuits
Low DC resistance design enhances energy efficiency

Fixed Inductors Applications

Power delivery networks
DC-DC converter output filtering
Point-of-load regulation stages

Fixed Inductors Procurement Notes

Verify the specific package dimensions against the official datasheet, as this series utilizes non-standard footprints that may differ from common SMD sizes. Confirm thermal management requirements for the target application, as high-current operation generates significant heat. Ensure the PCB layout accommodates the unique terminal configuration and spacing defined by the manufacturer's mechanical drawing.

Fixed Inductors Selection Notes

Select this component when high current handling is required alongside compact shielding. Compare the 7 A continuous current rating against peak load demands to ensure reliability. Evaluate the 32 mΩ resistance impact on overall system efficiency. Consider the non-standard footprint during initial PCB design to avoid layout constraints associated with standard packages.

Fixed Inductors Part Context

This part belongs to the SRP5030CC series of shielded power inductors. The series is characterized by its robust wirewound technology and high current density. It complements other Bourns magnetic products used in industrial and consumer electronics where space-saving and EMI reduction are critical design factors.
