SUTW101212

SUTW101212 is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Cosel USA, Inc.. Its product description is DC DC CONVERTER +/-12V 24V 11W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for SUTW101212

• Description：DC DC CONVERTER +/-12V 24V 11W
• Series：SUTW (10W)
• Mfr：Cosel USA, Inc.
• Package：Box
• Type：Isolated Module
• Number of Outputs：2
• Voltage - Input (Min)：9V
• Voltage - Input (Max)：18V
• Voltage - Output 1：12V
• Voltage - Output 2：-12V
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：450mA, 450mA
• Power (Watts)：11 W
• Voltage - Isolation：500 V
• Applications：ITE (Commercial)
• Features：-
• Operating Temperature：-40°C ~ 85°C (With Derating)
• Efficiency：86%
• Mounting Type：Through Hole
• Package / Case：7-SIP Module
• Size / Dimension：1.78" L x 0.36" W x 1.15" H (45.2mm x 9.2mm x 29.3mm)
• Supplier Device Package：-

DC DC Converters datasheet and documents for SUTW101212
