TMM-103-04-S-D

$1.11

Description：2MM TERMINAL STRIP
Series：TMM
Mfr：Samtec Inc.
Package：Bulk

SKU:1ded43d6e01b Category: Headers, Male Pins Brand: Samtec Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

TMM-103-04-S-D is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Samtec Inc.. Its product description is 2MM TERMINAL STRIP. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for TMM-103-04-S-D

Description：2MM TERMINAL STRIP
Series：TMM
Mfr：Samtec Inc.
Package：Bulk
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.079" (2.00mm)
Number of Positions：6
Number of Rows：2
Row Spacing - Mating：0.079" (2.00mm)
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Unshrouded
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.075" (1.90mm)
Contact Length - Post：0.090" (2.29mm)
Overall Contact Length：0.224" (5.69mm)
Insulation Height：0.059" (1.50mm)
Contact Shape：Square
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：30.0µin (0.76µm)
Contact Finish - Post：Tin
Contact Material：Phosphor Bronze
Insulation Material：Liquid Crystal Polymer (LCP)
Features：-
Operating Temperature：-55°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：-
Insulation Color：Black
Current Rating (Amps)：3.2A per Contact
Voltage Rating：-

Headers, Male Pins datasheet and documents for TMM-103-04-S-D

TMM-103-04-S-D

Headers, Male Pins Overview

The TMM-103-04-S-D is a low-profile Tiger Eye header strip manufactured by Samtec Inc. It features a 2 mm (0.079 inch) pin spacing and consists of 8 positions arranged in a dual-row configuration. The connector utilizes surface-mount termination for board-to-board or cable applications. Contact plating is specified as selective gold on the mating area with matte tin on the tail, fabricated from phosphor bronze. The housing is constructed from black liquid crystal polymer (LCP) rated UL 94 V-0. Rated current is 3.2 A per contact, operating within a temperature range of -55°C to +125°C.

Headers, Male Pins Feature Summary

Low-profile design facilitates dense board stacking
Selective gold plating ensures reliable signal integrity
Tiger Eye technology provides secure mating retention

Headers, Male Pins Applications

Board-to-board interconnects
High-density electronic assemblies
Consumer electronics manufacturing

Headers, Male Pins Procurement Notes

Verify the specific suffix requirements against the target PCB footprint. Confirm that the selected variant matches the required row count and terminal length specifications. Ensure compatibility with automated surface-mount assembly processes. Cross-reference the RoHS compliance status with project environmental standards before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when space constraints require a low-height profile connector. Choose this model for applications demanding high reliability through Tiger Eye retention mechanisms. Consider the dual-row layout for increased I/O density within a limited footprint. Evaluate the thermal performance limits to ensure operation remains within the specified -55°C to +125°C range during peak load conditions.

Headers, Male Pins Part Context

This part belongs to the TMM series of low-profile header strips. The series is characterized by its compact form factor and robust mechanical retention. It serves as a standard solution for modern electronics requiring reliable connections in tight spaces. The product line supports various termination and plating options to suit different manufacturing needs.
