TSM-104-01-LM-DV-LC-P-TR

Headers, Male Pins Overview

The Samtec TSM-104-01-LM-DV-LC-P-TR is a surface mount terminal strip featuring an .100 inch (2.54 mm) pitch and two rows of eight male pin contacts. It utilizes .025 inch square posts with gold plating for mating surfaces and matte tin for termination. The housing is constructed from black liquid crystal polymer (LCP) rated UL 94 V-0. Designed for vertical mounting, this component supports current ratings between 4.1 A and 5.4 A and operates within a temperature range of -55°C to +125°C.

Headers, Male Pins Feature Summary

• Features .025 inch square post terminals designed for high reliability and extended life applications.
• Constructed with LCP insulation material providing UL 94 V-0 flammability rating.
• Includes push-pull fastening mechanism for secure board attachment during surface mount assembly.

Headers, Male Pins Applications

• High-density board-to-board interconnections requiring surface mount technology
• Automotive electronic systems meeting stringent environmental standards
• Industrial control modules needing reliable signal transmission

Headers, Male Pins Procurement Notes

Verify the specific suffix configuration against official Samtec documentation to ensure correct contact length and termination type. Confirm RoHS compliance status and moisture sensitivity level requirements prior to integration. Cross-reference the reel packaging specifications to match automated placement equipment capabilities. Ensure the selected variant aligns with the intended thermal profile for soldering processes.

Headers, Male Pins Selection Notes

Select this component when a robust surface mount header with square post geometry is required for high-cycle mating environments. The .100 inch pitch offers compatibility with standard PCB layouts while the LCP housing ensures stability in demanding thermal conditions. Consider the push-pull feature for enhanced mechanical retention compared to standard solder-only headers. Evaluate the current carrying capacity against the specific circuit load requirements.

Headers, Male Pins Part Context

This part belongs to the TSM series of .100 inch surface mount terminal strips manufactured by Samtec. The series is characterized by its flexible stacking solutions and availability in single, double, and triple row configurations. These components are engineered for mixed technology applications, supporting both vertical and horizontal orientations to accommodate diverse design constraints.

Headers, Male Pins Replacement Considerations

TSM-104-01-SM-DV-LC

Headers, Male Pins FAQ

What is the mating cycle capability of this terminal strip?

The TSM series is designed as an Extended Life Product, capable of achieving high mating cycles ranging from 250 to 2,500 depending on the specific configuration.

Does this component meet severe environment testing standards?

Yes, the TSM series is SET qualified, meaning it meets or exceeds MIL-DTL-55302 testing standards for severe environmental conditions.
