TSW-120-29-T-S-RA

Headers, Male Pins Overview

TSW-120-29-T-S-RA is a board connector manufactured by Samtec Inc. It features 20 contacts arranged in a single row of female sockets with right-angle orientation and solder terminals. The component is RoHS compliant and utilizes matte tin plating on the contact interface. Designed for through-hole board installation, it serves as a socket within the TSW series, offering multiple mating parts availability.

Headers, Male Pins Feature Summary

• Right-angle PCB socket configuration
• Matte tin plated phosphor bronze contacts
• Single row low insertion force design

Headers, Male Pins Applications

• General purpose board-to-board interconnects
• Prototype and development boards
• Retrofit applications requiring right-angle access

Headers, Male Pins Procurement Notes

Verify that the specific suffix 'T' corresponds to matte tin plating rather than gold, as this affects corrosion resistance and cost. Confirm the right-angle orientation matches the PCB layout constraints. Ensure the 20-position count aligns with the circuit requirements. Check for any specific RoHS compliance documentation if required by the target market regulations.

Headers, Male Pins Selection Notes

Select this part when a right-angle female socket is needed for a single-row connection. The matte tin finish is suitable for general environments but may require protection against sulfidation compared to gold. Verify that the mating header is from the compatible TSW or TSQ series to ensure proper fit and electrical continuity.

Headers, Male Pins Part Context

This component belongs to the TSW (Terminal Strip With) series by Samtec. It is a classic PCB header strip designed for through-hole mounting. The series offers various configurations including straight and right-angle options with different pitch and contact counts to support diverse electronic assembly needs.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other .100 inch pitch right-angle socket strips from manufacturers like Molex or TE Connectivity. Ensure the replacement maintains the same 20-contact count, single row arrangement, and through-hole termination style for direct interchangeability.
