1-794072-1

$10.08

Description：CONN HEADER VERT 24POS 4.14MM
Series：Mini-Universal MATE-N-LOK
Mfr：TE Connectivity AMP Connectors
Package：Bulk

SKU:c92efe924e61 Category: Headers, Male Pins Brand: TE Connectivity AMP Connectors

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

1-794072-1 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists TE Connectivity AMP Connectors. Its product description is CONN HEADER VERT 24POS 4.14MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for 1-794072-1

Description：CONN HEADER VERT 24POS 4.14MM
Series：Mini-Universal MATE-N-LOK
Mfr：TE Connectivity AMP Connectors
Package：Bulk
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.163" (4.14mm)
Number of Positions：24
Number of Rows：2
Row Spacing - Mating：0.163" (4.14mm)
Number of Positions Loaded：All
Style：Board to Cable/Wire
Shrouding：Shrouded - 4 Wall
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Locking Ramp
Contact Length - Mating：-
Contact Length - Post：0.175" (4.45mm)
Overall Contact Length：-
Insulation Height：0.531" (13.50mm)
Contact Shape：Circular
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：30.0µin (0.76µm)
Contact Finish - Post：Tin
Contact Material：Brass
Insulation Material：Polyamide (PA), Nylon
Features：Board Lock
Operating Temperature：-20°C ~ 105°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：White
Current Rating (Amps)：Varies by Wire Gauge
Voltage Rating：600VAC

Headers, Male Pins datasheet and documents for 1-794072-1

1-794072-1

Headers, Male Pins Overview

The 1-794072-1 is a TE Connectivity AMP Connectors header, part of the MATE-N-LOK series. It features a 24-position, dual-row configuration with male pin contacts. The connector utilizes a 4.14mm pitch and is designed for vertical through-hole PCB mounting. Contacts are tin-plated brass, supporting a 600VAC rating. The housing is white nylon with UL 94 V-0 flammability classification.

Headers, Male Pins Feature Summary

Dual-row header design for high-density board-to-wire connections
Vertical through-hole termination for secure PCB installation
Tin-plated brass contacts ensure reliable conductivity
Nylon housing provides structural integrity and flame resistance

Headers, Male Pins Applications

Industrial control panel wiring
Power distribution systems
General-purpose electronic equipment interconnects

Headers, Male Pins Procurement Notes

Verify the specific suffix against official TE Connectivity documentation to confirm plating and orientation details. Ensure compatibility with mating socket connectors within the same MATE-N-LOK series. Confirm that the 600VAC rating aligns with system requirements. Check for any recent product change notices affecting material composition or manufacturing origin.

Headers, Male Pins Selection Notes

Select this component when a robust, high-current vertical header is required. The 4.14mm pitch accommodates larger wire gauges compared to standard signal headers. Verify that the through-hole footprint matches the PCB layout. Consider the mechanical locking features provided by the MATE-N-LOK system for vibration resistance in industrial environments.

Headers, Male Pins Part Context

This connector belongs to the Mini-Universal MATE-N-LOK family, known for heavy-duty performance. It complements other 24-position variants like 1-794072-0. The series is widely used in applications requiring durable electrical connections between circuit boards and external wiring harnesses.
