2157603025

Headers, Male Pins Overview

The Molex 2157603025 is a Micro-Fit+ Versa Color right-angle header connector designed for through-hole PCB mounting. It features a 5-position single-row configuration with a 3.00mm (0.118 inch) mating pitch. The component utilizes male pin contacts and is constructed with a black housing. This specific part number represents the header receptacle intended for mating with corresponding Micro-Fit+ Versa Color terminals.

Headers, Male Pins Feature Summary

• Right-angle orientation for space-efficient board layout
• Through-hole termination method for secure PCB attachment
• Micro-Fit+ Versa Color series compatibility

Headers, Male Pins Applications

• General electronic equipment interconnects
• Industrial control systems
• Consumer electronics assemblies

Headers, Male Pins Procurement Notes

Verify that the required contact count matches the five positions of this specific header variant. Confirm that the mating side utilizes compatible Micro-Fit+ Versa Color female terminals, as headers and receptacles are distinct components within the system. Ensure the through-hole footprint on the target PCB aligns with the specified 3.00mm pitch dimensions to guarantee proper mechanical fit and electrical connection during assembly.

Headers, Male Pins Selection Notes

Select this component when a right-angle, five-position connection is required in a 3.00mm pitch application. The Micro-Fit+ Versa Color series offers color-coded options for visual identification. Consider the through-hole mounting style if surface-mount alternatives are unsuitable for the mechanical stress requirements of the design.

Headers, Male Pins Part Context

This connector belongs to the Micro-Fit+ Versa Color family, which provides versatile interconnection solutions. The series is characterized by its compact size and reliable performance in various environments. The 2157603025 specifically denotes the right-angle header variant within this lineup, distinguishing it from straight or different position counts available in the same product family.

Headers, Male Pins Replacement Considerations

Direct replacements must maintain the 3.00mm pitch, five-position count, and right-angle through-hole configuration. Verify housing color and terminal compatibility if substituting with other manufacturers' equivalents to ensure mechanical and electrical interoperability.
