305-016-500-208

Edgeboard Connectors Overview

The EDAC Inc. 305-016-500-208 is a standard card edge connector featuring 16 positions in a dual female configuration. It utilizes a 3.96 mm (0.156 inch) contact spacing with a 3.56 mm row spacing, designed for nominal 1.57 mm thick printed circuit boards. The connector employs gold-plated copper alloy contacts and a green thermoplastic insulator body. Rated for 5 A current at temperatures ranging from -40°C to +105°C, it supports panel mounting via flush mount flanges with top openings and threaded inserts.

Edgeboard Connectors Feature Summary

• Dual edge female contact configuration for secure board insertion
• Gold-plated copper alloy contacts ensure reliable conductivity
• Panel mount design with flush flange and threaded insert options
• Low profile insulator body constructed from thermoplastic material

Edgeboard Connectors Applications

• Industrial control system interconnections
• Telecommunications equipment backplanes
• Test and measurement instrument modules
• Embedded computing hardware interfaces

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix against the manufacturer datasheet to confirm exact flange features and termination style. Ensure compatibility with the target PCB thickness of 1.57 mm. Confirm that the 3.96 mm pitch aligns with the mating card edge design. Check regional availability as distribution status may vary by location.

Edgeboard Connectors Selection Notes

Select this component when a dual-row connection is required for 16-position applications. The 3.96 mm pitch suits standard industrial board layouts. Verify that the panel mounting method matches the enclosure design requirements. Ensure the operating temperature range meets the environmental conditions of the intended deployment site.

Edgeboard Connectors Part Context

This part belongs to the EDAC 305 series of standard card edge connectors. The series offers various position counts and mounting styles. The 305-016-500-208 specifically addresses low-profile needs with dual-edge access. It complements other EDAC solutions for modular electronic systems requiring robust mechanical retention.

Edgeboard Connectors Replacement Considerations

Cross-reference with EDAC 305-018-555-208 for similar specifications but different position counts. Verify dimensional compatibility before substitution. Ensure electrical ratings match the application requirements.
