307-034-455-207

Edgeboard Connectors Overview

The EDAC Inc. 307-034-455-207 is a standard card edge connector receptacle featuring 34 positions arranged in a dual-row configuration. It utilizes a 3.96 mm (0.156 inch) contact spacing with a 5.08 mm row pitch. The component accepts printed circuit boards with a nominal thickness of 1.57 mm (0.062 inch). Electrical specifications include a current rating of 5 A and an insulation resistance of 5 GOhms. The operating temperature range spans from -40°C to +105°C.

Edgeboard Connectors Feature Summary

• Dual-edge female contacts designed for non-specified board types
• Low-profile insulator body construction
• Gold-plated copper alloy contacts for reliable conductivity

Edgeboard Connectors Applications

• Panel-mounted electronic interconnects
• Vertical PCB mounting applications
• Industrial control system backplanes

Edgeboard Connectors Procurement Notes

Verify the specific contact plating finish against official datasheets, as variations exist within the series. Confirm that the target PCB thickness aligns strictly with the 1.57 mm nominal requirement to ensure proper mechanical retention. Check RoHS compliance status directly with the manufacturer documentation prior to final procurement decisions.

Edgeboard Connectors Selection Notes

Select this component when a vertical, panel-mount solution is required for double-sided edge cards. Ensure the design accommodates the 5.08 mm row spacing alongside the 3.96 mm pin pitch. This part is suitable for environments requiring operation between -40°C and +105°C with a 5 A current capacity per contact.

Edgeboard Connectors Part Context

This component belongs to the EDAC 307 Series of standard card edge connectors. The series provides various position counts and mounting styles. The 307-034-455-207 specifically addresses needs for 34-position dual-row connections with vertical orientation, distinguishing it from single-row or horizontal variants within the same family.

Edgeboard Connectors Replacement Considerations

Compatible substitutes within the EDAC 307 series include 307-034-455-202 for tin-plated contacts and 307-034-455-207 for gold-plated headers. Verify exact pin count and row alignment before substitution.
