3221-26-0300-00

Headers, Male Pins Overview

The CNC Tech 3221-26-0300-00 is a surface mount shrouded header connector featuring 26 positions arranged in a dual-row configuration. It utilizes a 1.27mm (0.050 inch) mating pitch and offers an insulation height of 5.40mm. The component employs square male pins with gold plating on both the contact and post surfaces, ensuring reliable signal transmission. Designed for board-to-cable or wire applications, it includes keying features and pick-and-place compatibility to facilitate automated assembly processes.

Headers, Male Pins Feature Summary

• Surface mount installation with push-pull fastening type
• Shrouded design providing four-wall shielding
• Keyed construction for precise alignment
• Compatible with automated pick-and-place manufacturing

Headers, Male Pins Applications

• Industrial interconnection systems
• Data communication equipment
• Telecommunications infrastructure
• Consumer electronics assemblies

Headers, Male Pins Procurement Notes

Verify that the specific ordering suffix matches the required packaging format, as variations exist between tape and reel or cut tape options. Confirm that the component meets RoHS compliance standards for your region. Ensure the selected variant aligns with the necessary lead time requirements, as standard delivery periods may extend up to twenty weeks depending on current supply chain conditions.

Headers, Male Pins Selection Notes

Select this component when a low-profile, high-density connection is required for surface-mounted designs. The 1.27mm pitch allows for compact circuit layouts while maintaining robust mechanical stability. Consider the shrouded housing for improved pin protection during handling. Verify that the operating temperature range of -40°C to 105°C suits the environmental conditions of the target application.

Headers, Male Pins Part Context

This part belongs to the 3221 series of rectangular connectors manufactured by CnC Tech, LLC. The company specializes in industrial cable and connector solutions, focusing on cost-effective yet high-quality interconnect products. This series is designed to meet rigorous industrial standards, offering reliable performance in demanding environments through optimized material selection and manufacturing processes.

Headers, Male Pins Replacement Considerations

Direct substitutes within the same series include the 3221-20-0300-00 for reduced pin counts. Cross-brand replacements require matching the 1.27mm pitch, 26-position count, and surface mount footprint. Verify that any alternative maintains the same shrouded height and keying configuration to ensure mechanical compatibility.
