395-018-558-288

Edgeboard Connectors Overview

The EDAC Inc. 395-018-558-288 is a standard card edge connector from the 395 Series, designed for vertical board-to-board or backplane applications. It features an 18-position configuration with a 0.100 inch (2.54mm) pitch. The connector utilizes gold-plated contacts and a black insulator body. It is specified as a female dual-edge connector, intended for use with double-sided card edge PCBs.

Edgeboard Connectors Feature Summary

• Dual-edge contact design accommodates double-sided card edge printed circuit boards
• Vertical mounting orientation facilitates direct board insertion
• Gold-plated contact surfaces ensure reliable signal transmission

Edgeboard Connectors Applications

• Industrial control systems requiring modular interface connections
• Telecommunications equipment utilizing standardized card formats
• Test and measurement instrumentation with interchangeable modules

Edgeboard Connectors Procurement Notes

Verify that the target application requires a dual-edge connector compatible with double-sided card edges, as single-edge variants exist within the same series. Confirm that the PCB thickness aligns with the connector's mechanical specifications to ensure proper retention and electrical contact. Cross-reference the specific ordering suffix to confirm the exact contact plating and insulator color requirements for the intended environment.

Edgeboard Connectors Selection Notes

Select this component when a vertical, dual-edge connection is required for an 18-position interface. Ensure the mating card edge has conductive traces on both sides to utilize the dual-contact design. Compare against other 395 Series options if different mounting angles or position counts are needed. Verify that the 0.100 inch pitch matches the existing PCB layout constraints.

Edgeboard Connectors Part Context

This part belongs to the EDAC 395 Series of card edge connectors, which offers various configurations including single and dual-edge options in multiple position counts. The series is characterized by its robust construction and standardized 0.100 inch pitch, widely used in industrial and commercial electronics for reliable interconnect solutions.

Edgeboard Connectors Replacement Considerations

Direct substitutes include other 395 Series parts with identical 18-position dual-edge specifications, such as 395-018-558-112 if single-edge compatibility is acceptable. Verify mechanical dimensions and contact plating before substitution.
