Description：395 SERIES (.100" (2.54MM) CONTA
Series：395
Mfr：EDAC Inc.
Package：Box

SKU:586400f78593 Category: Edgeboard Connectors Brand: EDAC Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

395-140-521-802 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists EDAC Inc.. Its product description is 395 SERIES (.100" (2.54MM) CONTA. Review the specifications below when checking this part for your BOM.

Edgeboard Connectors specifications for 395-140-521-802

Description：395 SERIES (.100" (2.54MM) CONTA
Series：395
Mfr：EDAC Inc.
Package：Box
Card Type：Non Specified - Dual Edge
Gender：Female
Number of Positions/Bay/Row：70
Number of Positions：140
Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
Number of Rows：2
Pitch：0.100" (2.54mm)
Read Out：Dual
Features：-
Mounting Type：Through Hole
Termination：Solder
Contact Material：Copper Alloy
Contact Finish：Gold
Contact Finish Thickness：10.0µin (0.25µm)
Contact Type：Cantilever
Color：Black
Flange Feature：Top Mount Opening, Unthreaded, 0.128" (3.25mm) Dia
Operating Temperature：-40°C ~ 105°C

Edgeboard Connectors datasheet and documents for 395-140-521-802

395-140-521-802

Edgeboard Connectors Overview

The EDAC Inc. 395-140-521-802 is a dual-edge female card edge connector designed for vertical panel mounting applications. It features 140 positions arranged in two rows with a 0.100-inch (2.54mm) contact pitch. The connector utilizes gold-plated contacts and black thermoplastic polyester insulation, supporting board thicknesses of 0.054 to 0.070 inches. Rated for operation between -40°C and +105°C, it employs solder pin termination for secure PCB attachment.

Edgeboard Connectors Feature Summary

Dual-edge female configuration for non-specified card types
Gold-plated copper alloy contacts for reliable signal transmission
Vertical panel mount design with top-mounting flange openings
Thermoplastic polyester insulation housing for durability

Edgeboard Connectors Applications

Industrial control systems requiring high-density interconnects
Telecommunications equipment backplanes
Automotive electronics modules
Medical device circuit boards

Edgeboard Connectors Procurement Notes

Verify the specific suffix codes against official EDAC documentation to ensure correct termination style and plating specifications. Confirm that the required board thickness falls within the 0.054 to 0.070 inch range for proper mechanical engagement. Check RoHS compliance status if environmental regulations apply to your assembly process.

Edgeboard Connectors Selection Notes

Select this component when a high-pin-count, dual-sided connection is required for vertical panel integration. Ensure the mating card edge thickness matches the specified tolerance to guarantee consistent electrical contact. Consider the 140-position capacity relative to available panel space and routing requirements.

Edgeboard Connectors Part Context

This part belongs to the EDAC 395 series of standard card edge connectors. The series offers various position counts and termination options for diverse industrial and commercial applications. The 395-140 variant specifically addresses needs for substantial I/O density in constrained vertical spaces.
