3RS18001HP01

3RS18001HP01 is listed in the Power Relays, Over 2 Amps range at ChipApex. The manufacturer field lists Siemens. Its product description is RELAY GEN PURP 3PDT 3A 24-240V. Review the specifications below when checking this part for your BOM.

Power Relays, Over 2 Amps specifications for 3RS18001HP01

• Description：RELAY GEN PURP 3PDT 3A 24-240V
• Series：SIRIUS 3RS18
• Mfr：Siemens
• Package：Box
• Mounting Type：DIN Rail
• Coil Voltage：24 ~ 240VAC
• Contact Form：3PDT (3 Form C)
• Contact Rating (Current)：3:00 AM
• Switching Voltage：250VAC - Max
• Load - Max Switching：750VA
• Coil Current：-
• Coil Type：Non Latching
• Features：-
• Termination Style：Screw Terminal
• Seal Rating：-
• Coil Insulation：-
• Must Operate Voltage：-
• Must Release Voltage：-
• Operating Temperature：-25°C ~ 60°C
• Contact Material：-
• Approval Agency：CCC, CSA, EAC, UL
• Relay Type：General Purpose
• Grade：-
• Qualification：-
• Operate Time：-
• Release Time：-

Power Relays, Over 2 Amps datasheet and documents for 3RS18001HP01
