499-13-204-10-003000

$7.12

Description：CONN RCPT 4POS 0.1 GOLD PCB R/A
Series：499
Mfr：Mill-Max Manufacturing Corp.
Package：Bulk

SKU:a93874696c10 Category: Headers, Receptacles, Female Sockets Brand: Mill-Max Manufacturing Corp.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

499-13-204-10-003000 is listed in the Headers, Receptacles, Female Sockets range at ChipApex. The manufacturer field lists Mill-Max Manufacturing Corp.. Its product description is CONN RCPT 4POS 0.1 GOLD PCB R/A. Review the specifications below when checking this part for your BOM.

Headers, Receptacles, Female Sockets specifications for 499-13-204-10-003000

Description：CONN RCPT 4POS 0.1 GOLD PCB R/A
Series：499
Mfr：Mill-Max Manufacturing Corp.
Package：Bulk
Connector Type：Receptacle
Contact Type：Female Socket
Style：Board to Board
Number of Positions：4
Number of Positions Loaded：All
Pitch - Mating：0.100" (2.54mm)
Number of Rows：2
Row Spacing - Mating：0.100" (2.54mm)
Mounting Type：Through Hole, Right Angle
Termination：Solder
Fastening Type：Push-Pull
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：30.0µin (0.76µm)
Insulation Color：Black
Insulation Height：0.200" (5.08mm)
Contact Length - Post：0.126" (3.20mm)
Operating Temperature：-
Material Flammability Rating：-
Contact Finish - Post：Gold
Mated Stacking Heights：-
Ingress Protection：-
Features：-
Current Rating (Amps)：-
Voltage Rating：-

Headers, Receptacles, Female Sockets datasheet and documents for 499-13-204-10-003000

499-13-204-10-003000

Headers, Receptacles, Female Sockets Overview

The Mill-Max 499-13-204-10-003000 is a standard socket header designed for through-hole mounting. It features a two-row configuration with a 2.54mm pitch, providing four contact positions per row. The component utilizes wave soldering assembly methods and includes an insulation height of 5.08mm. This interconnect solution is engineered to facilitate reliable electrical connections between printed circuit boards and mating headers in electronic assemblies.

Headers, Receptacles, Female Sockets Feature Summary

Two-row pin receptacle architecture
Standard 2.54mm pitch spacing
Through-hole wave soldering compatibility

Headers, Receptacles, Female Sockets Applications

General-purpose PCB interconnection
Board-to-board signal routing
Electronic test fixture interfaces

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific RoHS compliance status and environmental certifications directly with the manufacturer or authorized distributors before procurement. Confirm that the package dimensions and insulation height align with your PCB layout requirements. Ensure that the wave soldering process parameters are compatible with the component's thermal specifications to maintain connection integrity during assembly.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a low-profile, two-row header with a 2.54mm pitch is required for through-hole applications. Consider the 5.08mm insulation height for clearance constraints. Evaluate the mechanical stability provided by the wave soldering mount against vibration and thermal cycling conditions inherent in the target environment.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Mill-Max 499 series of standard socket headers. The series is characterized by precision-machined contacts and standardized packaging options. These components are widely used in industrial and commercial electronics where reliable, repeatable connections are necessary for system operation and maintenance.
