7012X13

$0.50

Description：LED YELLOW CLEAR 0805 SMD
Series：BrightChips™
Mfr：Visual Communications Company - VCC
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:7cb3b6362e24 Category: LED Indication - Discrete Brand: Visual Communications Company - VCC

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

7012X13 is listed in the LED Indication - Discrete range at ChipApex. The manufacturer field lists Visual Communications Company - VCC. Its product description is LED YELLOW CLEAR 0805 SMD. Review the specifications below when checking this part for your BOM.

LED Indication - Discrete specifications for 7012X13

Description：LED YELLOW CLEAR 0805 SMD
Series：BrightChips™
Mfr：Visual Communications Company - VCC
Package：Tape & Reel (TR),Cut Tape (CT)
Color：Yellow
Configuration：Standard
Lens Color：-
Lens Transparency：Clear
Millicandela Rating：3.7mcd
Lens Style：Rectangle with Flat Top
Lens Size：1.19mm x 1.25mm
Voltage - Forward (Vf) (Typ)：2.2V
Current - Test：20mA
Viewing Angle：-
Mounting Type：Surface Mount
Wavelength - Dominant：-
Wavelength - Peak：580nm
Features：-
Package / Case：0805 (2012 Metric)
Supplier Device Package：805
Size / Dimension：2.00mm L x 1.25mm W
Height (Max)：0.79mm
Grade：-
Qualification：-

LED Indication - Discrete datasheet and documents for 7012X13

7012X13

LED Indication - Discrete Overview

The 7012X13 is an obsolete surface-mount LED from Visual Communications Company, packaged in a 0805 (2012 metric) case. It emits yellow light with a peak wavelength of 580nm and a dominant wavelength of 590nm. The component features a clear lens configuration and operates at a typical forward voltage of 2.2V when tested at 20mA. Its luminous intensity is rated at 40mcd, with a viewing angle of 150 degrees. The physical dimensions are 2.00mm in length, 1.25mm in width, and a maximum height of 0.79mm.

LED Indication - Discrete Feature Summary

Yellow light emission with clear lens transparency
Standard surface mount installation in 0805 package
Wide 150-degree viewing angle for visibility

LED Indication - Discrete Applications

General purpose indicator lighting
Electronic status indication
Control panel signaling

LED Indication - Discrete Procurement Notes

This component is officially obsolete and no longer manufactured by Visual Communications Company. Procurement must focus on verified substitute part numbers or available surplus stock from authorized distributors. Verify that replacement components match the original electrical parameters, specifically the 2.2V forward voltage and 0805 footprint, to ensure circuit compatibility.

LED Indication - Discrete Selection Notes

Due to the discontinued status of the 7012X13, selection requires identifying functionally equivalent yellow LEDs in the 0805 SMD package. Key verification points include matching the 580nm peak wavelength, 2.2V forward voltage, and mechanical dimensions. Ensure the substitute maintains the required 150-degree viewing angle and luminous intensity for the intended application.

LED Indication - Discrete Part Context

The 7012X13 belongs to the VCC discrete LED family designed for surface-mount technology. It was engineered for compact electronic assemblies requiring reliable visual feedback. As an obsolete part, it represents a legacy design point for yellow indication applications within the 0805 form factor, now replaced by newer manufacturing lines.
