78299-424HLF

Description：CONN HEADER R/A 24POS 2.54MM
Series：BERGSTIK® II
Mfr：Amphenol ICC (FCI)
Package：Bulk

SKU:277bf99c45bd Category: Headers, Male Pins Brand: Amphenol ICC (FCI)

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

78299-424HLF is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Amphenol ICC (FCI). Its product description is CONN HEADER R/A 24POS 2.54MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for 78299-424HLF

Description：CONN HEADER R/A 24POS 2.54MM
Series：BERGSTIK® II
Mfr：Amphenol ICC (FCI)
Package：Bulk
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：24
Number of Rows：2
Row Spacing - Mating：0.100" (2.54mm)
Number of Positions Loaded：All
Style：Board to Board
Shrouding：Unshrouded
Mounting Type：Through Hole, Right Angle
Termination：Press-Fit, Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.230" (5.84mm)
Contact Length - Post：0.120" (3.05mm)
Overall Contact Length：-
Insulation Height：0.190" (4.83mm)
Contact Shape：Square
Contact Finish - Mating：Tin
Contact Finish Thickness - Mating：100.0µin (2.54µm)
Contact Finish - Post：Tin
Contact Material：Phosphor Bronze
Insulation Material：Polycyclohexylenedimethylene Terephthalate (PCT)
Features：-
Operating Temperature：-
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：-
Voltage Rating：-

Headers, Male Pins datasheet and documents for 78299-424HLF

78299-424HLF

Headers, Male Pins Overview

The Amphenol ICC (FCI) model 78299-424HLF is a BergStik II series header connector designed for through-hole termination. It features an unshrouded, dual-row configuration with 24 positions and a standard 2.54 mm pitch. The contacts are male pins constructed from phosphor bronze with gold plating to ensure reliable signal transmission. Rated for 3 A current and 1.5 kV voltage, the unit utilizes a black thermoplastic housing. It is specified for right-angle mounting at 90 degrees relative to the PCB.
