800-10-053-65-001101

$11.96

Description：CONN HEADER VERT 53POS 2.54MM
Series：800
Mfr：Preci-Dip
Package：Bulk

SKU:f99e51e35ebf Category: Headers, Male Pins Brand: Preci-Dip

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

800-10-053-65-001101 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Preci-Dip. Its product description is CONN HEADER VERT 53POS 2.54MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for 800-10-053-65-001101

Description：CONN HEADER VERT 53POS 2.54MM
Series：800
Mfr：Preci-Dip
Package：Bulk
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：53
Number of Rows：1
Row Spacing - Mating：-
Number of Positions Loaded：All
Style：Board to Board
Shrouding：Unshrouded
Mounting Type：Through Hole
Termination：Press-Fit, Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.191" (4.85mm)
Contact Length - Post：0.110" (2.79mm)
Overall Contact Length：0.427" (10.85mm)
Insulation Height：0.116" (2.95mm)
Contact Shape：Circular
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：10.0µin (0.25µm)
Contact Finish - Post：Gold
Contact Material：Bronze
Insulation Material：Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
Features：-
Operating Temperature：-55°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：3A
Voltage Rating：150VDC

Headers, Male Pins datasheet and documents for 800-10-053-65-001101

800-10-053-65-001101

Headers, Male Pins Overview

The Preci-Dip 800-10-053-65-001101 is a single-row, 53-position pin header connector from the 800 series. It features a 2.54 mm (0.100 inch) pitch and utilizes bronze contacts with gold plating for reliable signal transmission. Designed for surface mount installation, it employs a wave soldering assembly process. The unit supports a rated current of 3A and a voltage of 150V DC. Constructed with black insulating material, it operates within a temperature range of -55°C to +125°C and meets UL94 V-0 flammability standards.

Headers, Male Pins Feature Summary

Surface mount design optimized for wave soldering processes
Gold-plated bronze contacts ensure stable electrical performance
High-temperature resistant insulation suitable for harsh environments

Headers, Male Pins Applications

Board-to-board interconnections in compact electronics
Signal routing in high-density circuit boards
Industrial control system interface modules

Headers, Male Pins Procurement Notes

Verify that the specific ordering suffix corresponds to the required surface mount configuration and contact finish. Confirm compatibility with wave soldering profiles during integration. Ensure procurement channels provide original manufacturer documentation to validate component authenticity and technical specifications against official datasheets.

Headers, Male Pins Selection Notes

Select this model when surface mount technology is required for single-row connections. The gold plating offers superior corrosion resistance compared to tin variants. Verify that the 53-position count matches the circuit board layout requirements. Consider the thermal stability limits when designing for extreme operating conditions.

Headers, Male Pins Part Context

This component belongs to the Preci-Dip 800 series, which provides versatile rectangular connector solutions. The series includes various mounting styles and contact finishes. This specific part represents the surface mount variant within the standard 2.54 mm pitch family, offering flexibility for automated assembly lines.
