878980204

$0.55

Description：CONN HEADER SMD 2POS 2.54MM
Series：C-Grid SL 87898
Mfr：Molex
Package：Tray

SKU:8139d631026e Category: Headers, Male Pins Brand: Molex

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

878980204 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Molex. Its product description is CONN HEADER SMD 2POS 2.54MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for 878980204

Description：CONN HEADER SMD 2POS 2.54MM
Series：C-Grid SL 87898
Mfr：Molex
Package：Tray
Connector Type：Header, Breakaway
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：2
Number of Rows：1
Row Spacing - Mating：-
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Unshrouded
Mounting Type：Surface Mount
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.230" (5.84mm)
Contact Length - Post：-
Overall Contact Length：-
Insulation Height：0.098" (2.50mm)
Contact Shape：Square
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：15.0µin (0.38µm)
Contact Finish - Post：Tin
Contact Material：Copper Alloy
Insulation Material：Polyamide (PA), Nylon, Glass Filled
Features：-
Operating Temperature：-
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：-
Voltage Rating：-

Headers, Male Pins datasheet and documents for 878980204

878980204

Headers, Male Pins Overview

Molex part number 878980204 is a C-Grid Series vertical surface mount pin header. It features two contacts in a single row with a 2.54 mm pitch. The connector utilizes SL technology and is constructed from nylon material with selective gold plating on the contacts. Designed for board-to-board or wire-to-board applications, it supports straight surface mount termination.

Headers, Male Pins Feature Summary

Vertical orientation for space-efficient PCB mounting
Selective gold plating for reliable signal transmission
Single-row configuration with two contact positions

Headers, Male Pins Applications

Board-to-board interconnections
Wire-to-board connections
High-performance electronic assemblies

Headers, Male Pins Procurement Notes

Verify the exact manufacturer part number against official Molex documentation to ensure compatibility with your design requirements. Confirm that the selected component matches the specified series and contact configuration. Cross-reference datasheets for mechanical dimensions and electrical ratings before finalizing procurement decisions.

Headers, Male Pins Selection Notes

Select this component when a low-profile, vertical header is required for high-density layouts. Ensure the mating connector aligns with the 2.54 mm pitch specification. Consider the surface mount package type and the specific contact plating requirements for your application environment.

Headers, Male Pins Part Context

This part belongs to the Molex C-Grid Series, which is designed for high performance and durability in harsh conditions. The SL technology provides robust connectivity solutions suitable for demanding industrial and commercial applications requiring reliable signal integrity.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided data. Verify compatibility with existing tooling and mating connectors if considering alternative sources.
