901310783

Headers, Male Pins Overview

Molex part number 0901310783 is a C-Grid III series vertical header connector designed for through-hole mounting. It features 46 positions arranged in a dual row with a 2.54mm (0.100 inch) mating pitch. The connector utilizes male pin contacts made of brass, featuring gold plating on the mating interface and tin plating on the tail for soldering. The housing is constructed from black polyester reinforced with glass fiber, rated UL94 V-0 for flammability. Key dimensions include an insulation height of 2.50mm, a contact length of 6.75mm for mating, and a total contact length of 12.15mm.

Headers, Male Pins Feature Summary

• Vertical board-to-cable/wire configuration with push-pull locking style
• Gold-plated mating surfaces ensure reliable signal transmission
• Glass-reinforced polyester insulation provides structural stability and fire resistance

Headers, Male Pins Applications

• Automotive electronic systems
• General industrial equipment interconnections
• Board-to-wire assembly applications

Headers, Male Pins Procurement Notes

Verify the specific suffix against the official Molex datasheet to confirm exact pin count and packaging specifications. Ensure compatibility with mating connectors within the C-Grid III family. Confirm that the required quantity matches the tray packaging format provided by authorized distributors. Cross-reference the RoHS compliance certificate if environmental regulations apply to the end product.

Headers, Male Pins Selection Notes

Select this component when a high-density vertical connection is required with a standard 2.54mm pitch. The 46-position dual-row layout suits applications needing extensive I/O in a compact footprint. Consider the through-hole termination method for robust mechanical anchoring. Verify that the operating temperature range of -55°C to +125°C meets the environmental demands of the installation site.

Headers, Male Pins Part Context

This connector belongs to the Molex C-Grid III interconnection system, which is engineered for high reliability in demanding environments. The 90131 series specifically addresses the need for secure, vertical connections between printed circuit boards and cables or wires. The design emphasizes durability and consistent electrical performance across automotive and general industrial sectors.

Headers, Male Pins Replacement Considerations

Compatible substitutes must match the 46-position count, 2.54mm pitch, and vertical orientation. Ensure alternative headers support through-hole termination and possess equivalent insulation material ratings. Verify that the mating interface dimensions align with existing C-Grid III counterparts to maintain mechanical integrity.
