Arrays, Edge Type, Mezzanine (Board To Board) 91901-31115LF product image

91901-31115LF

$1.66

Description：CONN HDR 15POS SMD GOLD
Series：Conan™, MezzSelect™
Mfr：Amphenol ICC (FCI)
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:9e303fa6dc52 Category: Arrays, Edge Type, Mezzanine (Board to Board) Brand: Amphenol ICC (FCI)

ChipApex WhatsApp

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

91901-31115LF is listed in the Arrays, Edge Type, Mezzanine (Board To Board) range at ChipApex. The manufacturer field lists Amphenol ICC (FCI). Its product description is CONN HDR 15POS SMD GOLD. Review the specifications below when checking this part for your BOM.

Arrays, Edge Type, Mezzanine (Board To Board) specifications for 91901-31115LF

Description：CONN HDR 15POS SMD GOLD
Series：Conan™, MezzSelect™
Mfr：Amphenol ICC (FCI)
Package：Tape & Reel (TR),Cut Tape (CT)
Connector Type：Header, Center Strip Contacts
Number of Positions：15
Pitch：0.039" (1.00mm)
Number of Rows：2
Mounting Type：Surface Mount
Features：Solder Retention
Contact Finish：Gold or Gold, GXT™
Contact Finish Thickness：15.0µin (0.38µm)
Mated Stacking Heights：4.15mm
Height Above Board：0.034" (0.86mm)

Arrays, Edge Type, Mezzanine (Board To Board) datasheet and documents for 91901-31115LF

91901-31115LF
