929647-03-17-EU

Headers, Male Pins Overview

The 3M 929647-03-17-EU is a single-row male pin header from the 929 series, designed for through-hole PCB mounting. It features a 2.54 mm (0.100 inch) pitch and provides 17 positions with all pins loaded. The connector utilizes copper alloy contacts with gold plating and a black PCT insulator rated UL94 V-0. It supports a current rating of 2.5 A and withstands voltages up to 1.5 kV. Operating temperatures range from -40°C to 105°C.

Headers, Male Pins Feature Summary

• Single-row male pin configuration with breakaway capability for custom lengths
• High-temperature PCT insulation suitable for wave or infrared soldering processes
• Gold-plated copper alloy contacts ensuring reliable electrical performance
• Through-hole termination style with push-pull locking mechanism

Headers, Male Pins Applications

• Board-to-board interconnections in industrial control systems
• Line-to-board connections within automated manufacturing equipment
• Signal routing in high-density electronic assemblies requiring thermal stability

Headers, Male Pins Procurement Notes

Verify component authenticity by cross-referencing the manufacturer part number with official 3M documentation. Confirm that the specific suffix matches the required contact count and row configuration. Ensure compliance with RoHS directives if applicable to the target assembly. Check datasheet revisions for any updates regarding material specifications or environmental ratings prior to final procurement decisions.

Headers, Male Pins Selection Notes

Select this component when a single-row, 2.54 mm pitch header is required for through-hole applications. Consider the 2.5 A current rating and 1.5 kV voltage limit for circuit compatibility. The PCT material choice is critical for designs involving wave or infrared soldering due to its high thermal resistance. Verify that the 17-position count aligns precisely with the board layout requirements.

Headers, Male Pins Part Context

This part belongs to the 3M 929 series of headers and wire housings. The series offers versatile options including single and double rows with various plating choices such as gold, matte tin, or tin-lead. These connectors are engineered for robust performance in demanding environments, supporting both standard and high-temperature soldering techniques while maintaining consistent electrical integrity across diverse industrial applications.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation.
