95C06F2RAT

95C06F2RAT is listed in the Tactile Switches range at ChipApex. The manufacturer field lists Grayhill Inc.. Its product description is SWITCH TACTILE SPST-NO 0.05A 12V. Review the specifications below when checking this part for your BOM.

Tactile Switches specifications for 95C06F2RAT

• Description：SWITCH TACTILE SPST-NO 0.05A 12V
• Series：95C
• Mfr：Grayhill Inc.
• Package：Bulk,Bag
• Circuit：SPST-NO
• Switch Function：Off-Mom
• Contact Rating @ Voltage：0.05A @ 12VDC
• Actuator Type：Plunger for Cap
• Mounting Type：Through Hole, Right Angle
• Actuator Height off PCB, Vertical：-
• Actuator Length, Right Angle：6.15mm
• Actuator Orientation：Side Actuated
• Termination Style：PC Pin
• Outline：7.40mm x 6.55mm
• Illumination：Non-Illuminated
• Illumination Type, Color：-
• Illumination Voltage (Nominal)：-
• Operating Force：100gf
• Ingress Protection：-
• Features：Tactile Feedback
• Operating Temperature：-25°C ~ 70°C

Tactile Switches datasheet and documents for 95C06F2RAT
