AC-12.000MDE-T

Oscillators Overview

The AC-12.000MDE-T is a standard CMOS quartz oscillator manufactured by TXC Corporation, operating at a frequency of 12 MHz. It features a supply voltage range of 1.8V and supports an enable/disable function for power management. The device exhibits a frequency stability of ±50 ppm over the temperature range of -40°C to +85°C. It is housed in a compact 4-SMD, no lead package with dimensions of 5.0 mm x 3.2 mm. This component holds AEC-Q100 certification, ensuring compliance with automotive grade standards.

Oscillators Feature Summary

• AEC-Q100 certified for automotive reliability
• Integrated enable/disable control functionality
• CMOS output signal format

Oscillators Applications

• Automotive electronic systems
• General purpose timing circuits
• Embedded system clock generation

Oscillators Procurement Notes

Verify the specific ordering suffixes against the manufacturer's official documentation to ensure compatibility with required voltage levels and packaging formats. Confirm that the selected variant meets the precise environmental and electrical specifications mandated by your target application design requirements.

Oscillators Selection Notes

Select this component when a 12 MHz reference clock is required for automotive or industrial applications demanding AEC-Q100 qualification. The integrated enable pin allows for dynamic power management, making it suitable for battery-operated or energy-efficient designs requiring precise timing synchronization.

Oscillators Part Context

This part belongs to the AC series of standard oscillators from TXC Corporation, designed specifically for high-reliability environments. The series utilizes ceramic resonator technology to provide stable frequency generation. It complements other automotive-grade timing solutions within the manufacturer's portfolio.

Oscillators Replacement Considerations

Direct substitutes include the 7C-12.000MDE-T, which shares similar automotive certification and performance characteristics. Verify pinout compatibility and thermal specifications before implementing any alternative components in existing designs.
