AL1411C-3C

Overview

The AL1411C-3C is a surface-mount RGB LED component manufactured by Solidlite. It features a compact lens size of 2.40mm diameter and overall dimensions of 3.20mm length by 2.80mm width. The device operates with a typical forward voltage of 2.1V for the red channel, while green and blue channels require 3.2V. Each color channel is rated for a test current of 20mA. Optical performance includes a millicandela rating of 275mcd for red, 900mcd for green, and 275mcd for blue.

Feature Summary

• Integrated tri-color RGB configuration within a single surface-mount package
• Compact physical footprint suitable for space-constrained designs
• Standardized electrical parameters for red, green, and blue channels

Applications

• Status indication in consumer electronics
• Backlighting for control panels
• Decorative lighting modules

Procurement Notes

Verify the specific suffix variant against official Solidlite documentation to ensure compatibility with required optical intensity and chromaticity standards. Confirm that the selected part number matches the intended mounting orientation and thermal requirements for the target assembly process.

Selection Notes

Select this component when a unified RGB source is required for discrete LED applications. Consider the 20mA test current requirement and distinct forward voltages for circuit design. Ensure the 2.40mm lens diameter meets visibility needs compared to larger packages.

Part Context

This model belongs to Solidlite's range of discrete LED indicators. It provides a multi-color solution in a small form factor, differing from single-color variants or larger through-hole options. The component supports standard surface-mount technology processes.

Replacement Considerations

Cross-reference with other Solidlite RGB models such as SP0605A-3C if dimensional constraints differ. Verify pinout and electrical characteristics before substituting with generic RGB LEDs to ensure functional equivalence.
