ALS31A472NT500

ALS31A472NT500 is listed in the Aluminum Electrolytic Capacitors range at ChipApex. The manufacturer field lists KEMET. Its product description is CAP ALUM SCREW TERM 85C. Review the specifications below when checking this part for your BOM.

Aluminum Electrolytic Capacitors specifications for ALS31A472NT500

• Description：CAP ALUM SCREW TERM 85C
• Series：ALS31
• Mfr：KEMET
• Package：Box
• Capacitance：4.7 mF
• Tolerance：±20%
• Voltage - Rated：500 V
• ESR (Equivalent Series Resistance)：37mOhm @ 100Hz
• Lifetime @ Temp.：5000 Hrs @ 85°C
• Operating Temperature：-40°C ~ 85°C
• Polarization：Polar
• Ratings：-
• Applications：General Purpose
• Ripple Current @ Low Frequency：24.3 A @ 100 Hz
• Ripple Current @ High Frequency：33.3 A @ 10 kHz
• Lead Spacing：1.252" (31.80mm)
• Size / Dimension：3.031" Dia (77.00mm)
• Height - Seated (Max)：8.740" (222.00mm)
• Surface Mount Land Size：-
• Mounting Type：Chassis Mount
• Package / Case：Radial, Can - Screw Terminals
• Impedance：24 mOhms

Aluminum Electrolytic Capacitors datasheet and documents for ALS31A472NT500
