AM2520SECK09
Search Product
Search Post
— IC芯片 | 连接器 | 传感器 | 被动器件 —
Consult the customer manager about the wholesale price.
consultation hotline：86-132-6715-2157
email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.
Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.
Product Detailed Parameters
- Description：LED ORANGE CLEAR SMD BOTTOM ENT
- Series：-
- Mfr：Kingbright
- Package：Tape & Reel (TR),Cut Tape (CT)
- Color：Orange
- Configuration：Standard
- Lens Color：Colorless
- Lens Transparency：Clear
- Millicandela Rating：1800mcd
- Lens Style：Round with Domed Top
- Lens Size：1.90mm Dia
- Voltage - Forward (Vf) (Typ)：2.1V
- Current - Test：20mA
- Viewing Angle：20°
- Mounting Type：Surface Mount, Bottom Entry
- Wavelength - Dominant：601nm
- Wavelength - Peak：610nm
- Features：-
- Package / Case：2-SMD, Z-Bend
- Supplier Device Package：SMD
- Size / Dimension：2.50mm L x 2.00mm W
- Height (Max)：2.90mm
- Grade：-
- Qualification：-
Download product information
Overview
The Kingbright AM2520SECK09 is a single-color orange surface-mount LED from the KM2520 series. It features a water-clear dome lens with dimensions of 2.5 mm length, 2.0 mm width, and 2.8 mm height. The component emits light at a peak wavelength of 601 nm with a viewing angle of 20 degrees. Typical forward voltage is 2.1 V at a test current of 20 mA, while maximum power dissipation is rated at 75 mW. Light intensity reaches 1.8 cd (1800 mcd). It operates within a temperature range of -40°C to +85°C and carries RoHS compliance.
Feature Summary
- Ultra-compact 2-SMD package design suitable for space-constrained surface-mount applications
- Water-clear epoxy lens provides high transparency and optical clarity for efficient light emission
- Dome-shaped lens geometry ensures a focused 20-degree viewing angle for directional indication
Applications
- Panel status indicators in consumer electronics
- Front panel illumination for portable devices
- Equipment status signaling in industrial control systems
Procurement Notes
Verify the specific suffix '09' against the manufacturer datasheet to confirm the exact binning for light intensity and wavelength. Ensure the ordering code matches the required reel or cut-tape packaging format. Confirm RoHS3 compliance requirements align with project specifications before finalizing procurement orders.
Selection Notes
Select this component when a low-profile orange indicator is required for dense PCB layouts. The 2.5x2.0 mm footprint allows for tight spacing compared to larger LEDs. Consider the 2.1 V forward voltage drop for circuit design calculations. Verify that the 1.8 cd intensity meets visibility requirements for the intended application environment.
Part Context
This part belongs to the Kingbright KM2520 family of ultra-small SMD LEDs. The series offers various colors and intensities in a standardized 2-SMD form factor. The AM2520SECK09 specifically denotes the orange variant with clear lens and standard intensity bins within this compact product line.
Replacement Considerations
The part number alias KM2520SECK09 may be used interchangeably depending on distributor coding. Direct substitutes require matching 2.5x2.0 mm dimensions, 601 nm wavelength, and compatible forward voltage characteristics.
