AM2D-052424DZ

AM2D-052424DZ is listed in the DC DC Converters range at ChipApex. The manufacturer field lists aimtec. Its product description is DC DC CONVERTER 2X24V 2W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for AM2D-052424DZ

• Description：DC DC CONVERTER 2X24V 2W
• Series：AM2D-Z (2W)
• Mfr：aimtec
• Package：Tube
• Type：Isolated Module
• Number of Outputs：2
• Voltage - Input (Min)：4.5V
• Voltage - Input (Max)：5.5V
• Voltage - Output 1：24V
• Voltage - Output 2：24V
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：42mA, 42mA
• Power (Watts)：2 W
• Voltage - Isolation：1 kV
• Applications：ITE (Commercial)
• Features：-
• Operating Temperature：-40°C ~ 85°C
• Efficiency：75%
• Mounting Type：Through Hole
• Package / Case：7-SIP Module
• Size / Dimension：0.76" L x 0.28" W x 0.39" H (19.5mm x 7.2mm x 10.0mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：CE
• Standard Number：-

DC DC Converters datasheet and documents for AM2D-052424DZ
