APDA3020VBC/D

Overview

The APDA3020VBC/D is a surface-mount infrared emitting diode manufactured by Kingbright. It features a right-angle package design with dimensions of 3.0 mm in length and 2.0 mm in width. The device emits at a peak wavelength of 940 nm, suitable for data communication applications. It operates within a temperature range of -40°C to +85°C and complies with RoHS standards.

Feature Summary

• Right-angle surface mount configuration for compact board layout
• Infrared emission optimized for data communication systems
• Compliant with environmental directives including RoHS

Applications

• Infrared data transmission modules
• Remote control signal emitters
• Optical sensor interfaces

Procurement Notes

Verify the exact suffix designation (e.g., D) against the manufacturer's current datasheet to ensure correct optical and mechanical specifications. Confirm moisture sensitivity level handling requirements during assembly. Check for any product change notifications that may affect pinout or material composition prior to final procurement.

Selection Notes

Select this component when a right-angle form factor is required for infrared emission in space-constrained designs. Ensure the forward voltage and current ratings align with the driving circuit capabilities. Verify compatibility with automated pick-and-place equipment due to the specific package geometry.

Part Context

This part belongs to the Kingbright 3020 series of surface-mount LEDs. The series offers various colors and configurations, including right-angle options. The APDA3020VBC/D specifically targets infrared applications requiring directional emission perpendicular to the mounting surface.

Replacement Considerations

APDA3020F3C-P22
