APTC60DAM18CTG

$151.08

Description：MOSFET N-CH 600V 143A SP4
Series：CoolMOS™
Mfr：Microchip Technology
Package：Bulk

SKU:b415f3345f26 Category: Single FETs, MOSFETs Brand: Microchip Technology

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

APTC60DAM18CTG is listed in the Single FETs, MOSFETs range at ChipApex. The manufacturer field lists Microchip Technology. Its product description is MOSFET N-CH 600V 143A SP4. Review the specifications below when checking this part for your BOM.

Single FETs, MOSFETs specifications for APTC60DAM18CTG

Description：MOSFET N-CH 600V 143A SP4
Series：CoolMOS™
Mfr：Microchip Technology
Package：Bulk
FET Type：N-Channel
Technology：MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)：600 V
Current - Continuous Drain (Id) @ 25°C：143A (Tc)
Drive Voltage (Max Rds On, Min Rds On)：10V
Rds On (Max) @ Id, Vgs：18mOhm @ 71.5A, 10V
Vgs(th) (Max) @ Id：3.9V @ 4mA
Gate Charge (Qg) (Max) @ Vgs：1036 nC @ 10 V
Vgs (Max)：±30V
Input Capacitance (Ciss) (Max) @ Vds：28000 pF @ 25 V
FET Feature：-
Power Dissipation (Max)：833W (Tc)
Operating Temperature：-40°C ~ 150°C (TJ)
Grade：-
Qualification：-
Mounting Type：Chassis Mount
Supplier Device Package：SP4
Package / Case：SP4

Single FETs, MOSFETs datasheet and documents for APTC60DAM18CTG

APTC60DAM18CTG

Single FETs, MOSFETs Overview

The APTC60DAM18CTG is a chassis-mount discrete semiconductor module from Microchip Technology, integrating CoolMOS N-Channel Power MOSFETs with Schottky Barrier Diodes (SBD). It features a maximum drain-source voltage of 600V and a continuous drain current of 143A. The device exhibits a maximum on-resistance of 18mOhm at 71.5A with a 10V gate-source voltage. Thermal performance includes a maximum power dissipation of 833W.

Single FETs, MOSFETs Feature Summary

Integrates CoolMOS technology for optimized switching efficiency
Combines MOSFET and SBD in a single chassis-mount package
Designed for high-current applications with low on-resistance

Single FETs, MOSFETs Applications

High-efficiency power conversion systems
Industrial motor drives
Uninterruptible power supplies (UPS)

Single FETs, MOSFETs Procurement Notes

Verify the specific suffix 'CTG' against official Microchip documentation to confirm RoHS compliance and lead time requirements. Confirm thermal interface material specifications and mounting torque values prior to integration. Ensure compatibility with existing heatsink designs given the chassis-mount form factor.

Single FETs, MOSFETs Selection Notes

Select this component for applications requiring high current handling and low conduction losses. The integrated SBD reduces external component count. Evaluate thermal management capabilities against the 833W dissipation rating. Compare against other CoolMOS modules for voltage and current headroom.

Single FETs, MOSFETs Part Context

This part belongs to the PM-MOSFET-COOLMOS-SBD-SP4 product family. It utilizes silicon technology and is packaged in a tube. The module is designed for robust performance in demanding power electronics environments, leveraging Microchip's CoolMOS technology for improved efficiency.
