AS-16.9344MAHH-B

Description：CRYSTAL 16.9344MHZ 15PF TH
Series：AS
Mfr：TXC CORPORATION
Package：Bulk

SKU:91192d13aa4a Category: Crystals Brand: TXC CORPORATION

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

AS-16.9344MAHH-B is listed in the Crystals range at ChipApex. The manufacturer field lists TXC CORPORATION. Its product description is CRYSTAL 16.9344MHZ 15PF TH. Review the specifications below when checking this part for your BOM.

Crystals specifications for AS-16.9344MAHH-B

Description：CRYSTAL 16.9344MHZ 15PF TH
Series：AS
Mfr：TXC CORPORATION
Package：Bulk
Type：MHz Crystal
Frequency：16.9344 MHz
Frequency Stability：±30ppm
Frequency Tolerance：±30ppm
Load Capacitance：15pF
ESR (Equivalent Series Resistance)：50 Ohms
Operating Mode：Fundamental
Operating Temperature：-40°C ~ 85°C
Ratings：AEC-Q200
Mounting Type：Through Hole
Package / Case：HC-49/US
Size / Dimension：0.453" L x 0.197" W (11.50mm x 5.00mm)
Height - Seated (Max)：0.145" (3.68mm)

Crystals datasheet and documents for AS-16.9344MAHH-B

AS-16.9344MAHH-B

Crystals Overview

The AS-16.9344MAHH-B is a quartz crystal resonator manufactured by TXC Corporation, operating at a fundamental frequency of 16.9344 MHz. It features a frequency tolerance and stability of ±30 ppm across the industrial temperature range of -40°C to +85°C. The component utilizes a 12 pF load capacitance and is certified to AEC-Q200 automotive standards. It employs an HC49 surface-mount package with dimensions of 14.5 mm in length, 4.5 mm in width, and a maximum height of 3.68 mm. The device supports SMD/SMT termination types and is available in reel packaging.

Crystals Feature Summary

AEC-Q200 certified for automotive reliability requirements
High-frequency stability within ±30 ppm tolerance
HC49 surface-mount form factor for compact integration

Crystals Applications

Automotive electronic systems requiring precise timing
Industrial control equipment operating in extreme temperatures
Telecommunications infrastructure components

Crystals Procurement Notes

Verify that the specific part number matches the required frequency and tolerance specifications before procurement. Confirm that the HC49 surface-mount package dimensions align with the target PCB layout constraints. Ensure that the AEC-Q200 certification status meets the specific automotive or industrial quality standards mandated by the end-product design requirements.

Crystals Selection Notes

Select this component when a fundamental mode quartz crystal with strict automotive-grade stability is required. The ±30 ppm tolerance ensures reliable synchronization in digital communication interfaces. The wide operating temperature range makes it suitable for harsh environmental conditions where standard commercial crystals might fail due to thermal drift.

Crystals Part Context

This component belongs to the AS series of quartz crystals from TXC Corporation, designed specifically for high-reliability applications. The series emphasizes robust performance under varying thermal conditions while maintaining compact physical profiles. It serves as a critical timing reference for microcontrollers and communication modules in regulated industries.
