ATP101-TL-H

$1.01

Description：MOSFET P-CH 30V 25A ATPAK
Series：-
Mfr：onsemi
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:513fa30fae6e Category: Single FETs, MOSFETs Brand: onsemi

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

ATP101-TL-H is listed in the Single FETs, MOSFETs range at ChipApex. The manufacturer field lists onsemi. Its product description is MOSFET P-CH 30V 25A ATPAK. Review the specifications below when checking this part for your BOM.

Single FETs, MOSFETs specifications for ATP101-TL-H

Description：MOSFET P-CH 30V 25A ATPAK
Series：-
Mfr：onsemi
Package：Tape & Reel (TR),Cut Tape (CT)
FET Type：P-Channel
Technology：MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)：30 V
Current - Continuous Drain (Id) @ 25°C：25A (Ta)
Drive Voltage (Max Rds On, Min Rds On)：4.5V, 10V
Rds On (Max) @ Id, Vgs：30mOhm @ 13A, 10V
Vgs(th) (Max) @ Id：-
Gate Charge (Qg) (Max) @ Vgs：18.5 nC @ 10 V
Vgs (Max)：±20V
Input Capacitance (Ciss) (Max) @ Vds：875 pF @ 10 V
FET Feature：-
Power Dissipation (Max)：30W (Tc)
Operating Temperature：150°C (TJ)
Grade：-
Qualification：-
Mounting Type：Surface Mount
Supplier Device Package：ATPAK
Package / Case：ATPAK (2 Leads+Tab)

Single FETs, MOSFETs datasheet and documents for ATP101-TL-H

ATP101-TL-H

Single FETs, MOSFETs Overview

The ATP101-TL-H is a single P-channel silicon power MOSFET manufactured by onsemi. It features a maximum drain-source breakdown voltage of 30 V and supports a continuous drain current of 25 A. The device exhibits a maximum on-resistance of 0.03 ohms. It is housed in a small outline package with three pins, specifically the R-PSSO-G2 configuration. The component includes a built-in diode and connects its case to the drain terminal.

Single FETs, MOSFETs Feature Summary

Single P-channel enhancement mode MOSFET construction
Integrated body diode for switching applications
Case connected directly to the drain terminal

Single FETs, MOSFETs Applications

Power switching circuits
Low-side or high-side load control
DC-DC converter topologies

Single FETs, MOSFETs Procurement Notes

Verify the specific manufacturer designation as records indicate potential attribution to both SANYO and onsemi. Confirm the package code matches the required R-PSSO-G2 specification. Ensure compliance with lead-free requirements and check the reach compliance status before integration into final assemblies.

Single FETs, MOSFETs Selection Notes

Select this component for applications requiring a 30 V P-channel switch with moderate current handling capabilities. The low on-resistance minimizes conduction losses. Verify that the thermal management design accommodates the power dissipation limits inherent to the small outline package configuration under expected operating conditions.

Single FETs, MOSFETs Part Context

This part belongs to the family of surface-mount power MOSFETs designed for efficient switching. The ATPAK or similar compact packages allow for high-density PCB layouts. The device utilizes standard silicon technology optimized for robust performance in consumer and industrial electronic power stages.
