AVP6014S

Pulse Transformers Overview

The AVP6014S is a LAN discrete module manufactured by Pulse Electronics, designed for high-performance networking applications. It supports 2.5 Gigabit Ethernet speeds and integrates Power over Ethernet (PoE) capabilities with a 60W power rating across four pairs. The component utilizes surface-mount technology (SMD/SMT) for automated assembly. Key electrical specifications include an isolation voltage of 1.5 kVrms to ensure safety and signal integrity. The module operates within a temperature range of -40°C to +85°C, providing robust environmental resilience for diverse deployment scenarios.

Pulse Transformers Feature Summary

• Supports 2.5G data transmission rates for enhanced network throughput
• Integrates 60W Power over Ethernet (PoE) functionality across four pairs
• Provides 1.5 kVrms isolation voltage for circuit protection
• Utilizes surface-mount packaging for compact board integration

Pulse Transformers Applications

• 2.5 Gigabit Ethernet network infrastructure
• Power over Ethernet powered devices requiring up to 60W
• High-density networking equipment
• Enterprise switch modules

Pulse Transformers Procurement Notes

Verify the specific datasheet revision and RoHS compliance status directly with Pulse Electronics or authorized distributors before procurement. Confirm that the surface-mount footprint matches the design layout requirements. Ensure that the thermal management strategy accommodates the specified operating temperature range of -40°C to +85°C during PoE operation. Cross-reference the part number with official manufacturer catalogs to avoid counterfeit components.

Pulse Transformers Selection Notes

Select the AVP6014S when a single-component solution is required for both 2.5G data signaling and substantial PoE power delivery. This module is suitable for designs prioritizing space efficiency and simplified bill of materials compared to discrete transformer and inductor combinations. Evaluate the isolation voltage requirements against system safety standards. Consider the SMT package constraints for PCB routing and soldering processes.

Pulse Transformers Part Context

This component belongs to the LAN Discrete Modules category from Pulse Electronics, specifically engineered for modern Ethernet standards. It addresses the industry shift towards higher bandwidths like 2.5GBASE-T while maintaining compatibility with existing PoE power budgets. The module consolidates magnetic functions into a single SMD package, reducing assembly complexity and improving reliability in compact networking hardware designs.

Pulse Transformers Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
